A-FRAME & PIVOT BEAM PARTS

27

64060 (2005-810&8611SkidSteer).doc

QUANTITY

REF PART

NUMBER

810SS 8611SS

DESCRIPTION

41041 1

-

1

41052 -

1

Pivot Beam Weldment

2

61357

6

6

Pin, Cotter, 1/4" x 1-1/2" Z

3

50069

2

2

Pin, 3/4"Dia. x 3" Clevis YZ

4

41051

4

4

Pin, 3/4"Dia. x 5" Clevis YZ

5

61331

1

1

Screw, 1"-8 x 9" HHCS Gr8 P

6

61008

1

1

Nut, 1"-8 Top Lock Z

7

61217

4

4

Grommet, 1-1/2" I.D., 2-1/8" O.D. Black Rubber, 60 Durometer

60029 2

-

8

60324 -

2

Hydraulic Cylinder, Plow Angle

9

60223

2

-

Hydraulic Hose, 3/8" x 26" Plow Angle

10

60224

4

6

Hydraulic Hose, 3/8" x 36" Plow Angle

11

60005

2

2

Hydraulic Adapter, 9/16"-18 x 9/16"-18 90° Adjustable Elbow O.R.B.

12

70143

1

1

Mat, A-Frame Rubber

13 70134 1

1

Plate,

A-Frame

Cover

14

61214

7

7

Screw, 3/8-16 UNC x 1-1/4” HHCS

15

61016

11

11

Washer, 3/8” SAE Hardened

16

61514

2

2

Screw, 3/8-16 UNC x 4 HHCS

17

61328

1

1

Screw, 3/8-16 UNC x 1-1/2” HHCS

18

61307

1

1

Washer, 3/8” Internal/External Tooth Lock

19

60086

2

2

Hydraulic Hose, 3/4"x78" -str./str.

20 70132 1

1

A-frame

Weldment

21

61034

3

3

Nut, 3/8-16 UNC Hex Nylock

22 61275 7

7

U-Nut,

3/8-16

UNC

60341 1

-

23A

60342 -

1

Manifold Assembly

60354 1

-

23

60355 -

1

Manifold Block (with Cross Port Relief), Clear Anodized Aluminum
Manifold Block (with Cross Port Relief), Gold Anodized Aluminum

24

60089

2

2

Hydraulic Adapter, 1 1/16-12 x 1 1/16-12 Male O.R.B. connector

25

60320

1

1

Valve, Spool Two-Way N.O.

26

60356

1

1

Valve, Back Pressure Check 5PSI

27

60183

1

1

Valve, Pressure Compensation Regulation

28

60225

4

4

Valve, Check, 50 PSI

29

60272

6

6

Hydraulic Adapter, 9/16-18 x 9/16-18 Adj. Elbow

60279

2

-

Valve, Relief, 1500PSI

30

60227

-

2

Valve, Relief, 2650 PSI

31

60168

1

1

Valve, Relief, 3000 PSI

32

62163

5

5

Coil, PDL 12 VDC

33

60166

4

4

Valve, Spool, Three-Way, Two Position

34

60052

5

5

Nut, 1/2-20 Hex Jam, YZ

35A 62161 1

1

Coil Harness Assembly
Includes 62045 (1), 62118 (2), 62116 (5), 62096 (7), 62097 (7), Ref 32 & 36

35

60321

1

1

Valve, Four Way-Three Position Spool

36

62164

2

2

Coil, LDL 12 VDC

60278

2

-

Valve, Relief 1700 PSI

37

60226

-

2

Valve, Relief 2800 PSI

38

60049

2

2

Plug , SAE Hollow Hex O.R.B.

- 60322 2

2

Piston

Assembly
