MOLDBOARD & WING PARTS
25
64060 (2005-810&8611SkidSteer).doc
QUANTITY
REF PART NUMBER
810SS 8611SS
DESCRIPTION
52074 1 -
1
52085 - 1
Moldboard Weldment
2 61170 1 1 Label, WARNING! (Blz1013)
3 63160 1 1 Decal, Center Moldboard (Blz1070)
4 61171 1 1 Label, Skid Steer Mounting & Dismounting (Blz1014)
61292 1 -
5
52139 - 1
Cutting Edge, Moldboard (1080)
61196 7 - Bolt, 1/2"-13 x 1-1/2" Carriage Gr8
6
61623 - 7 Bolt, 5/8-11 UNC x 2" Carriage Gr8
61365 13 6 Nut, 1/2"-13 Flanged Lock Z
7
61626 - 7 Nut, 5/8"-11 Flanged Lock Z
51042 1 -
8
51100 - 1
Wing Weldment, Driver’s Side
61083 1 -
9
63065 - 1
Decal, Wing, Driver’s Side
51048 1 -
10
51069 - 1
Cutting Edge, Weldment Driver’s Wing (T1)
50057 1 -
11
50075 - 1
Slide Box, Weldment Drivers
12 63113 2 2 Label, Warning! Multiple Pinch Points (Blz1068)
13A 61220 2 2 Plow Shoe Asm, Heavy-Duty Cast Iron (8-3/8" Shaft) Includes Ref 13-15
13 61102 2 2 Spacer, 1-1/8" I.D., 1-5/8" O.D. x 1-1/2" YZ
14 61101 36 36 Washer, 1" Flat YZ
15 61103 2 2 Pin, 7/16" x 1-3/4" Linch YZ
16 63063 1 1 Label, Serial Number, Sequentially Numbered (Blz1049)
17 61383 4 4 Screw, 5/16"-18 x 2-1/4" HHCS Gr8 YZ
18 11871 4 4 Pin, 1" Dia. x 4-3/4"Slide Box Stop (with 3/8" Dia. hole)
19 61384 4 4 Nut, 5/16"-18 Top Lock Z
20A 61049 2 2 Plow Guide Assembly Includes Ref 20-21
20 61051 4 4 Screw, 5/16"-18 x 1" HHCS Gr5 Z
21 61052 4 4 Nut, 5/16"-18 Nylock Z
51043 1 -
22
51101 - 1
Wing Weldment, Passenger’s Side
61084 1 -
23
63064 - 1
Decal, Wing, Passenger’s Side
51047 1 -
24
51070 - 1
Cutting Edge, Weldment Passenger’s Wing (T1)
61418 2 - Bolt, 1/2"-13 x 3-1/2" Carriage Gr8 P
25
61360 - 2 Bolt, 1/2"-13 x 5" Carriage Gr8 P
26 61419 2 - Bolt, 1/2"-13 x 4-1/2" Carriage Gr8 P
27 61361 2 2 Bolt, 1/2"-13 x 5-1/2" Carriage Gr8 P
28 61362 - 2 Bolt, 1/2"-13 x 6-1/2" Carriage Gr8 P
50058 1 -
29
50074 - 1
Slide Box, Weldment Passenger
30 61416 2 2 Bolt, 5/8"-11 x 7-3/8" Spade Gr8 Z
31 61398 2 - Spring, 13" O.A.L. x 2" O.D. x 5/16" Extension
32 61099 4 8 Spring, 15-1/4" O.A.L. x 2-3/8" O.D. x 3/8" Extension
33 61385 2 2 Pin, 5/8" Dia. x 3" Clevis YZ
34 61028 2 2 Pin, 1/4" Dia. x 1-1/4" Spring
51009 2 - Pin, 3/4" Dia. x 9" Wing/Slide Box Pivot
35
13307 - 2 Pin, 1" Dia. x 11-1/8" Wing/Slide Box Pivot
36 61425 2 - Plug, 2-51/64" O.D., 2-9/32" I.D. x 1/2" Black Polyethylene
60347 2 -
37
60207 - 2
Hydraulic Cylinder, Slide Box Extend/Retract
38 61063 2 8 Nut, 5/8"-11 Top Lock Z
60007 4 - Hydraulic Adapter, 9/16"-18 x 9/16"-18 Male O.R.B.
39
60272 - 4 Hydraulic Adapter, 9/16"-18 x 9/16"-18 45° Adjustable Elbow O.R.B.
40 60224 4 4 Hydraulic Hose, 3/8" x 36" (Ports #7, 8, 9 & 10) Slide Box Extend/Retract
41 61198 2 2 Cap, 5/8" I.D., 3/4" O.D. x 1" Black Vinyl
42 11989 2 2
Pin, 5/8" Dia. x 11-1/2" Hydraulic Cylinder Base End (with 1/4" Dia. hole) - Slide Box
Extend/Retract
43 61030 2 2 Pin, 1/8" Dia. x 2-5/8" Hair Cotter Z
44 61187 4 6 Bolt, 5/8"-11 x 6-3/8" Spade Gr8 Z
45 61064 4 6 Washer, 5/8" SAE Hardened YZ
