ASSEMBLY INSTRUCTIONS
READ ALL SAFETY WARNINGS & ASSEMBLY INSTRUCTIONS CAREFULLY
BEFORE ASSEMBLING OR OPERATING YOUR GRILL.
WE RECOMMEND TWO PEOPLE WORK TOGETHER WHEN ASSEMBLING THIS UNIT.
The following provided tools are required to assemble this ProSeries ™ 9620 Gas Grill:
• Flathead Screwdriver
• Hex Nut Wrench
21
1 Left Side Cart Panel
1 Right Side Cart Panel
1 Left Door
1 Right Door
1 Upper Door Bracket
1 Back Panel
1 Rear Cart Brace/Tank Heat Shield
4 Locking Casters
1 Grease Tray
1 Tank Holder
1 Cart Base
2 Tank Block Bars
PARTS LIST:
1 Grill Body Assembly
1 Left Side Table Towel Rack
1 Left Side Table
1 Side Burner Assembly
1 Side Burner Grate
1 Side Burner Towel Rack
1 Left Side Table Front Panel
1 Side Burner Front Panel
1 Side Burner Bezel and Knob
1 Warming Rack
4 Cooking Grills
6 Heat Distribution Plates
1
2
3
4
5
6
7
8
9
10
11
13
14
15
16
17
18
19
20
22
23
21
24 12
