15
EURODESK MX2442A
The level to tape is ultimately determined by precision faders . Main mix insert points are provided for
patching a gate, a compressor etc. pre-fader. This is important: Connecting a compressor or gate after the
2-track output would disrupt any attempt to acquiring a smooth fade using the output faders.
Although the 2-track output is primarily designed for recording, it can also be used as a PA feed, or as a send
to the input of your sampler. In fact, up to three simultaneous destinations can be serviced without resorting to
a patchbay or splitter leads—there are three separate 2-track outputs on your EURODESK!
6.6 Talkback
The built-in flush-mounted mic is activated by depressing the non-latching TALK switch just above the
MAIN MIX faders. Engaging talkback dims the control room monitors, (not lights!) by -20 dB to avoid feedback.
This does not affect the other talkback routes.
Talkback level is set by
, and the mic can be routed to any or all of auxes 1/2 and 3/4 ( , )—in other
words, every possible pre-fader (cue) aux send—to enable you to talk to artists remotely through their headphones
or personal stage mixes.
Sometimes you will want a much higher rejection of feedback than a flush-mounted talkback mic could ever
provide. When running a live concert mix, a dynamic mic plugged into a spare channel and routed to all the
pre-fader sends only will do the job.
7. CONNECTIONS
7.1 EURODESK MX2442A Back Panel/Serial Number
DC power in
This circular multiway connector distributes the different DC operating voltages delivered by the PSU: +/-18 V
(audio circuits), +48 V (mic phantom power), +12 V (lamp) and +5 V (LEDs).
Phantom power switch
When using capacitor mics, +48 V DC can be switched globally on or off by (also see “Mic inputs”).
+
Care should be taken NOT to plug mics into the console (or stagebox) while the phantom
power is on. Also mute the monitor / PA speakers when turning phantom power on or off.
Allow 1 minute after powering up for the system to equilibrate before setting input gains.
Serial number
Please complete and return the warranty card within 14 days of the date of purchase. Otherwise, you will lose
your right to the extended warranty. Alternatively, you can register online at our website under www.behringer.com.
Your BEHRINGER MX2442A was carefully packed in the factory and the packaging was designed to protect
the unit from rough handling. Nevertheless, we recommend that you carefully examine the packaging and its
contents for any signs of physical damage, which may have occurred during transit.
+
If the unit is damaged, please do not return it to BEHRINGER, but notify your dealer and the
shipping company immediately, otherwise claims for damage or replacement may not be
granted. Shipping claims must be made by the consignee.
+
Before you connect your MX2442A to the mains, please make sure that your local voltage
matches the voltage required by the unit.
+
Please note that the PSU and mixer heat up during operation. This is absolutely normal.
