Philips HF3480-01 - Manual (Page 7)

3 Clock time symbol
4 Alarm symbol
5 Radio symbol
6 ’Birds’ sound symbol
7 ‘Beep’ sound symbol
8 ‘African jungle’ sound symbol
9 ‘Wind chimes’ sound symbol
10 Dusk simulation symbol
11 Display brightness symbol
12 Minute indication of clock/alarm time
13 Sound level symbol
F Dials on the side of the appliance
1 Top dial: light on/off and light intensity
2 Middle dial: menu and radio frequency
3 Bottom dial: radio on/off and volume
G Control lever with ‘alarm off’, ‘alarm on’ and ‘snooze’ positions
Preparing for use
Before first use
Note: You can also use the Wake-up Light without the base. You only have to install the base when you
want to use the Wake-up Light in combination with your iPod/iPhone.
1 Place the Wake-up Light 16-20in/40-50cm from your head, for example on a bedside
table (Fig. 5).
2 Put the plug in the wall outlet.
The hour indication on the display starts flashing to indicate that you have to set the clock -
time (Fig. 6).
setting the clock time
You cannot use the Wake-up Light until you have set the clock time.
1 When the hour indication on the display flashes, move the middle dial up or down to
select the hour.
2 Press the middle dial gently and release it to confirm.
The minute indication starts flashing (Fig. 7). ,
3 Move the middle dial up or down to select the minutes.
4 Press the middle dial gently and release it to confirm.
The appliance leaves the menu and the display shows the set clock time. ,
The appliance is now ready for use.
Note: Every time you remove the plug from the wall outlet for more than approximately 15 minutes, you
have to set the clock time again by following steps 1 to 4 above.
Note: To change the set clock time when the plug is still in the wall outlet, press the middle dial gently
two times to enter the menu for setting the clock time. You are in the menu when the hour indication
flashes. Then follow steps 1 to 4 above.
Using the appliance
Use this appliance for its intended household use as described in this manual.
EnglisH 10
Top and bottom dials
With the top dial you can switch the lamp on or off and set the light intensity (see section
-
‘Using the lamp’ in this chapter).
With the bottom dial you can switch the radio on or off and set the volume (see section ‘Radio/ -
volume’ in this chapter).
Note: Press the dial gently and release it to switch on or off the light (top dial) or radio (bottom dial)
and move the dial up or down to change the light intensity (top dial) or volume level (bottom dial).
Middle dial
The middle dial allows you to choose various functions from the menu. These functions appear in
the menu in the following order:
Clock time -
Alarm time -
Alarm sound -
Dusk simulation function -
Display brightness function -
You can operate the middle dial in the following way:
1 Press the middle dial gently and release it to enter the menu (Fig. 8).
Do not press the dial too hard. If you do, the dial does not work.
2 Move the middle dial up or down to select a function (Fig. 9).
3 Press the middle dial gently and release it to enter this function.
4 Move the middle dial up or down to select an option in this function.
5 Press the middle dial gently and release it to confirm.
If you do not operate the dial for 5 seconds when you are in the menu, the appliance
automatically leaves the menu and displays the clock time again.
setting the alarm
To set the alarm, you choose an alarm time and the type of sound you want to wake up to. The
alarm is set when the alarm symbol and the alarm sound symbol are visible on the display.
Note: You can set the light intensity by moving the top dial up or down and you can set the alarm volume
by moving the bottom dial up or down. If you do not want to wake up to the lamp or to a sound, select a
light intensity or volume level of 0 (shown on the display as ‘OFF’). See sections ‘Using the lamp’ and
‘Radio/volume’ in this chapter.
Tip: When you use the appliance for the first time, set the light intensity to 20. The moment you wake up,
check which light intensity level the appliance has reached by slightly moving the top dial up or down.
When you do this, the current alarm light intensity level appears on the display. Set the alarm light
intensity to this level for the next day.
1 Push the control lever down to the middle position to switch on the alarm (Fig. 10).
The hour indication of the alarm time flashes (Fig. 11). ,
To adjust the alarm time, follow steps 2 to 5 below. If the alarm time is correct, just wait a ,
few seconds.
2 Move the middle dial up or down to select the hour.
Note: You can only do this when the hour indication flashes. If this is not the case, push the control lever
up and down again to enter the alarm time function.
EnglisH 11
