ENGLISH
4
tape forward.
2. Press the REW button to rapidly wind the
tape backward.
Recording from the Radio
. Set the FUNCTION selector to RADIO and
turn to the desired station.
2. Press the STOP/EJ button to open the
cassette compartment door.
. Insert the cassette with the exposed portion
facing upward.
4. Close the cassette compartment door by
hand.
5. Press the PAUSE button, and then press the
REC button (PLAY button will be engaged
simultaneously).
6. To start recording, press the PAUSE button
to release.
7. To stop recording, press the STOP/EJ
button. To eject the cassette, press the
STOP/EJ button again.
Recording from Built-in Microphone
. Set the FUNCTION selector to TAPE.
2. Press the STOP/EJ button to open the
cassette compartment door.
. Insert the cassette with the exposed portion
facing upward.
4. Close the cassette compartment door by
hand.
5. Press the PAUSE button, and then press the
REC button (PLAY button will be engaged
simultaneously).
6. To start recording, press the PAUSE button
to release.
7. To stop recording, press the STOP/EJ
button. To eject the cassette, press the
STOP/EJ button again.
Notes:
• The recording level is adjusted
automatically. The VOLUME level does not
affect the recording level.
• If the sound on playback is distorted, the
microphone may have been placed too near
the recording source. Re-position the unit
and run through the above procedure again.
Erase Protection
During recording, any previous recordings on
the tape are automatically erased. To avoid ac-
cidental erasure, remove the erase protection
tab on the cassette’s back edge. If you break
the side A’s tab, you can not record on side A. If
you want to record on the tape, cover the tab’s
hole with a piece of plastic adhesive tape.
Headphones Jack
For private listening, insert the earphone’s plug
into the headphones jack of the unit. This auto-
matically disconnects the built-in speakers.
CARE AND MAINTENANCE
• Check that there are no loose layers on
tape. “Take up” these loose layers using a
pencil before inserting the cassette into the
cassette compartment.
• Do not use the C-20 (or longer) cassettes.
• Do not expose the unit to the extremes of
temperatures.
• Clean the tape handing parts (Play/record
head, pinch roller and capstan) after every
40-hours of operation with a cotton swab
moistened with denatured alcohol.
• Wipe away tough dirt with a soft cloth
soaked in a neutral detergent.
• Clean the body with a soft cloth. Do not use
chemicals.
Specifications
Radio
General
LW: 50-285 kHz
Output power: 0,5 W
MW: 540-600 kHz
FM: 88-08 MHz
Dimensions: 294 х 27 х 40 mm
Antenna
AM: Ferrite-bar antenna
Mass: ~ , 5 kg (without batteries)
FM: Telescopic antenna
Accessories: AC power cord
Tape
Tape speed: 4,75 cm/sec.
Power Requirements
AC: 220 V ~ 50 Hz
DC: 6 V, 4 х SUM- (“D” size, HP2, R20)
Specifications are subjected to change without
notice.
The service life of the device is no less than
five years.
Guarantee
Details regarding guarantee conditions can
be obtained from the dealer from whom the
appliance was purchased. The bill of sale or
receipt must be produced when making any
claim under the terms of this guarantee.
This product conforms to the EMC-
Requirements as laid down by the
Council Directive 89/6/EEC and to
the Low Voltage Regulation (2/7 EEC)
