Gourmet Oven Replacement Parts
24
Table 3. Heated Plenum Assembly (AB56201300) Parts
ITEM # PART # QTY DESCRIPTION
1 WB56201100 1 HEATED PLEN INSIDE WELD GO36
2 WB56201200 1 HEATED PLENUM OUTSIDE GO-36
3 FA56205002 3 BRACKET, ELEMENT RETAINING GO36
4 FB56205602 1 ACCESS PLATE, PLENUM OVER T SW
5 I0005 3 INSULATION, 1"TK
6 S0115 1 SWITCH, OVERTEMPERATURE
7 C0212 3 CALROD, 208/220V 1100W
8 F0158 1 BUSHING, BLK 1/2 HEYCO SNAP
9 RIV173 16 RIVET, SSD44 SSBS POP
10 SCR138 2 SCREW, 10 X 1/2 PHIL TR HD
11 NUT076 3 NUT, 10-24 PALNUTS
12 SCR334 2 SCREW, 4 X 3/8 SLTD PAN HD A
13 TP0026 7.5 ft. TAPE, SILICONE RUBBER 1" X 1/8
14 SCR077 3 SCREW, STUD 10-24 X 1/2 WELD
