BASS V-AMP LX1B/BASS V-AMP PRO LX1B PRO User Manual
Dimensions/Weight
Dimensions (H x W x D)
2 1/2 x 9 1/4 x 7 1/8"
63 x 236 x 180 mm
Weight
approx. 4.4 lbs / approx. 2 kg
BASS V-AMP PRO
Audio Inputs
Instrument Input
1/4" TS connector, unbalanced
Input impedance
1 MΩ
Max. input level
+3 dBu
Pre DSP Return Line In
1/4" TS connector, unbalanced
Input impedance
45 kΩ
Max. input level
+9 dBu
Post DSP Insert Return L/R
1/4" TS connector, unbalanced
Input impedance
40 kΩ
Max. input level
+8 dBu
Audio Outputs
Analog Line Outputs L/R
1/4" TS connectors, unbalanced
Output impedance
approx. 680 Ω
Max. output level
+20 dBu
Pre Dsp Send/Line Out
1/4" TS connector, unbalanced
Output impedance
<1 kΩ
Max. output level
+9 dBu
Post DSP Insert Send L/R
1/4" TS connectors, unbalanced
Output impedance
1 kΩ
Max. output level
+8 dBu
Balanced Line Out
XLR, balanced
Output impedance
100 Ω
Max. output level
+14 dBu (studio); 0 dBu (live)
Headphones
1/4" TRS connector, unbalanced
Max. output level
+15 dBu/100 Ω (+23 dBm)
Digital Outputs
XLR
transformer-balanced
Output impedance
110 Ω
Nom. output level
3.5 V peak-to-peak
RCA
not grounded, unbalanced
Output impedance
75 Ω
Nom. output level
0.5 V peak-to-peak
Format
AES/EBU or S/PDIF, selectable
Sample rate
44.1/48/96 kHz internal; 32 - 96 kHz
wordclock, sample rate converter
Wordclock Input
BNC
coaxial
Input impedance
50 kΩ
Nom. input level
2 - 6 V peak-to-peak
MIDI
Type
5-pole DIN jacks IN, OUT/THRU
Digital Signal Processing
Converter
24-bit Delta-Sigma,
64/128-times oversampling
Dynamics A/D
100 dB @ preamp bypass
Dynamics D/A
92 dB
Sample rate
31.250 kHz
DSP
100 Mips
Delay time
max. 1023 ms stereo/
sampler delay: 15.36 s
Run time (Line In Line Out)
approx. 5 ms
Display
Type
2-digit 7-segment-LED display
