ENGLISH
• 28 •
Repairs / Maintenance
- If the coffee machine falls and you see or
suspect damage or malfunctioning,
immediately remove the plug from the wall.
Never use faulty machines.
- Repairs must be made by an authorized service
centre only.
- If maintenance work and/or repairs are not
carried out by an authorized service centre,
the manufacturer will not be liable for
damages.
Fire Safety
- In the event of a fire, use carbon dioxide
extinguishers (CO
2
). Do not use water or
powder extinguishers.
DESCRIPTION OF PARTS
See Fig.01
1
Coffee bean container
2 Coffee bean container lid
(aroma preserver)
3 Grind adjustment lever
4 Dose adjustment lever
5 Ground coffee dispenser lid
6 Cup heater
7 ON-OFF switch
8 Water tank cover
9 Water tank
10 Dregs drawer
11 Power cord
12 Drip tray + plate
13 Height adjustable brew unit
14 Steam / hot water nozzle and tube
15 Side door
16 Steam knob
17 Brew unit
18 Control panel
19 Key of brew unit
20 Cleaning brush
21 Ground coffee measuring scoop
Control panel
22 Small coffee selector button
23 Normal coffee selector button
Page down in programming mode
24 Large coffee selector button
Page up in programming mode
25 Ground coffee selector button
Programming button
“OK” in the programming mode
26 Steam button
ESC in the programming mode
27 Button for enabling/disabling the standby
function.
28 LCD display
