—17—
DETAILED COOLING CAPACITIES * Continued
See notes on page 21.
EVAPORATOR
AIR
CONDENSER ENTERING AIR TEMPERATURES °F
85 95 105 115 125
CFM EWB
Capacity
MBtuh†
Total
System
Kw **
Capacity
MBtuh†
Total
System
Kw **
Capacity
MBtuh†
Total
System
Kw **
Capacity
MBtuh†
Total
System
Kw **
Capacity
MBtuh†
Total
System
Kw ** Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡ Total Sens‡
597CN036-F Outdoor Section With CC5A/CD5AA036 Indoor Section
1050
72 39.0 19.3 2.91 37.6 18.7 3.23 35.9 18.1 3.56 34.2 17.5 3.9 32.5 16.9 4.36
67 35.8 24.5 2.89 34.4 23.9 3.21 32.8 23.2 3.53 31.3 22.6 3.9 29.7 22.0 4.32
62 32.7 29.4 2.87 31.4 28.8 3.19 30.0 28.1 3.51 28.6 27.4 3.8 27.1 26.5 4.29
57 31.3 31.3 2.87 30.3 30.3 3.18 29.2 29.2 3.51 28.0 28.0 3.8 26.9 26.9 4.29
1200
72 39.7 20.2 2.97 38.2 19.6 3.29 36.5 19.0 3.62 34.8 18.4 4.0 32.8 17.7 4.40
67 36.4 26.0 2.95 35.0 25.4 3.27 33.4 24.7 3.60 31.8 24.1 3.9 30.2 23.5 4.39
62 33.4 31.4 2.94 32.0 30.7 3.24 30.6 29.9 3.59 29.1 28.9 3.9 27.8 27.8 4.34
57 32.5 32.5 2.93 31.4 31.4 3.25 30.3 30.3 3.58 29.0 29.0 3.9 27.8 27.8 4.35
1350
72 40.3 21.0 3.03 38.5 20.4 3.33 36.9 19.8 3.69 35.1 19.2 4.0 33.2 18.5 4.47
67 36.9 27.4 3.01 35.3 26.7 3.31 33.8 26.2 3.66 32.2 25.5 4.0 30.3 24.8 4.42
62 33.9 33.1 3.00 32.5 32.2 3.29 31.2 31.2 3.64 29.9 29.9 4.0 28.5 28.5 4.40
57 33.5 33.5 2.99 32.4 32.4 3.31 31.2 31.2 3.64 29.9 29.9 4.0 28.5 28.5 4.40
Multipliers for Determining the Performance With Other Indoor Sections
Indoor
Section Size
Cooling
Indoor
Section Size
Cooling
Capacity Power Capacity Power
CC5A/CD5AA 036 1.00 1.00 CE3AA 042 1.01 0.93
042 100 1.00 CK3BA 036 1.00 0.92
CC5A/CD5AW 042 1.00 1.00 042 1.00 0.93
CD5AW 036 1.00 1.00 CK5A/CK5BA 042 1.00 0.93
CE3AA 036 0.99 1.00 CK5A/CK5BW 036 1.00 0.92
042 1.01 1.00 COILS + 333(B,J)AV060100 VARIABLE SPEED FURNACE
CF5AA 036 1.01 1.00 CC5A/CD5AA 042 1.01 0.93
CK3BA 036 1.00 1.00 CE3AA 042 1.01 0.93
042 1.00 1.00 CK3BA 036 1.00 0.92
CK5A/CK5BA 036 1.00 1.00 042 1.00 0.92
042 1.00 1.00 CK5A/CK5BA 042 1.00 0.92
CK5A/CK5BN 036 0.94 1.00 CK5A/CK5BW 036 1.00 0.92
042 0.97 1.00 COILS + 333(B,J)AV060120 VARIABLE SPEED FURNACE
CK5A/CK5BW 036 1.00 1.00 CC5A/CD5AA 042 1.01 0.93
F(A,B)4ANF 036 1.00 1.00 CE3AA 042 1.01 0.93
F(A,B)4AN(F,B) 042 1.01 1.01 CK3BA 042 1.00 0.92
FC4BNF 036 1.00 1.00 CK5A/CK5BA 042 1.00 0.92
FC4BN(F,B) 042 1.01 1.01 CK5A/CK5BW 036 1.00 0.92
FC4BNB 054 1.03 1.00 COILS + 355MAV042040 VARIABLE SPEED FURNACE
FG3AAA 036 0.99 1.00 CC5A/CD5AA 036 1.01 0.92
FK4BNF 001 1.00 0.98 042 1.01 0.92
002 1.00 0.98 CK3BA 036 1.00 0.94
003 1.01 0.93 042 1.00 0.93
004 1.01 0.95 CK5A/CK5BA 042 1.00 0.93
FK4BNB 005 1.03 0.94 CK5A/CK5BW 036 1.00 0.94
006 1.03 0.93 COILS + 355MAV042060 VARIABLE SPEED FURNACE
FK4CNB 006 1.03 0.93 CC5A/CD5AA 036 1.01 0.92
FK4CNF 001 1.00 0.98 042 1.01 0.92
002 1.00 0.98 CK3BA 036 1.00 0.94
003 1.01 0.93 042 1.00 0.94
005 1.03 0.94 CK5A/CK5BA 036 1.00 0.94
COILS + 333(B,J)AV036060 VARIABLE SPEED FURNACE CK5A/CK5BN 042 0.97 0.94
CC5A/CD5AA 042 1.01 0.93 COILS + 355MAV042080 VARIABLE SPEED FURNACE
CE3AA 042 1.01 0.93 CC5A/CD5AA 036 1.01 0.92
CK3BA 036 1.00 0.94 042 1.01 0.92
042 1.00 0.94 CK3BA 036 1.00 0.93
CK5A/CK5BA 036 1.00 0.94 042 1.00 0.93
CK5A/CK5BN 036 0.94 0.93 CK5A/CK5BA 042 1.00 0.93
COILS + 333(B,J)AV048080 VARIABLE SPEED FURNACE CK5A/CK5BW 036 1.00 0.93
CC5A/CD5AA 042 1.01 0.93 — — —
