PERFORMANCE DATA (cont)
COOLING CAPACITIES (cont)
583B048 COOLING PERFORMANCE TABLE
Temp (F)
Outdoor Air
Entering
Condenser
Evaporator Air — CFM/BF
1200 / 0.06 1600 / 0.08 2000 / 0.11
Evaporator Air — Ewb (F)
62 67 72 62 67 72 62 67 72
75
TC
SHC
kW 48.9
42.4
3.38 53.3
35.5
3.43 57.8
28.7
3.48 51.5
49.2
3.68 55.8
40.2
3.78 60.1
31.0
3.82 53.4
53.4
4.01 57.5
44.4
4.23 61.2
32.5
4.27
85
TC
SHC
kW 46.7
41.2
3.77 51.2
34.8
3.80 55.7
27.9
3.86 49.4
48.3
4.03 53.7
39.4
4.16 58.2
30.4
4.21 51.7
51.7
4.36 55.2
43.7
4.63 59.5
32.2
4.68
95
TC
SHC
kW 44.3
40.0
4.15 49.0
33.8
4.23 53.3
27.0
4.28 47.0
47.0
4.41 51.3
38.6
4.57 55.8
29.6
4.63 49.9
49.9
4.78 52.6
43.0
5.07 57.1
31.5
5.11
105
TC
SHC
kW 40.1
37.3
4.67 44.7
31.5
4.79 48.8
25.1
4.82 43.1
43.1
4.93 46.6
36.2
5.14 50.9
27.5
5.19 45.7
45.7
5.34 47.8
40.5
5.60 52.4
29.5
5.66
115
TC
SHC
kW 36.1
35.2
5.32 40.6
29.7
5.50 44.6
23.5
5.54 39.7
39.7
5.65 42.3
34.4
5.85 46.3
25.8
5.89 42.0
42.0
6.06 43.4
38.7
6.27 47.4
28.0
6.36
125
TC
SHC
kW 32.7
32.7
6.16 36.2
27.7
6.31 39.6
21.5
6.34 35.9
35.9
6.47 37.4
32.4
6.63 41.2
23.9
6.69 37.7
37.7
6.89 38.4
36.4
7.04 42.2
26.1
7.16
583B060 COOLING PERFORMANCE TABLE
Temp (F)
Outdoor Air
Entering
Condenser
Evaporator Air — CFM/BF
1500 / 0.05 1750 / 0.06 2000 / 0.07 2500 / 0.08
Evaporator Air — Ewb (F)
62 67 72 62 67 72 62 67 72 62 67 72
75
TC
SHC
kW 60.1
52.7
4.63 66.7
44.6
4.69 72.4
35.6
4.75 62.2
57.7
4.67 68.5
47.9
4.71 74.2
37.5
4.78 64.2
62.1
4.68 70.0
51.1
4.73 75.6
39.3
4.80 67.5
67.5
4.70 72.1
56.8
4.75 77.5
42.6
4.84
85
TC
SHC
kW 56.9
51.3
5.06 63.3
43.2
5.17 69.4
34.6
5.21 58.8
55.9
5.10 65.4
46.7
5.17 71.1
36.5
5.23 60.5
60.5
5.14 66.9
50.1
5.18 72.4
38.3
5.26 64.7
64.7
5.17 68.8
56.0
5.21 74.1
41.5
5.29
95
TC
SHC
kW 53.7
49.8
5.54 59.9
41.7
5.68 66.2
33.4
5.72 55.5
54.3
5.58 61.9
45.3
5.68 67.7
35.3
5.74 57.6
57.6
5.64 63.2
48.7
5.69 68.9
37.1
5.76 61.8
61.8
5.68 65.1
54.9
5.71 70.6
40.5
5.79
105
TC
SHC
kW 48.1
46.3
6.17 54.2
38.7
6.35 60.0
30.7
6.39 50.1
50.1
6.23 55.8
42.1
6.36 61.4
32.7
6.41 52.6
52.6
6.30 56.9
45.3
6.37 62.4
34.4
6.42 56.2
56.2
6.36 58.6
51.4
6.38 63.8
37.6
6.44
115
TC
SHC
kW 44.2
44.2
6.75 50.0
36.9
6.94 55.5
29.0
6.98 46.8
46.8
6.83 51.3
40.1
6.95 56.7
30.8
6.99 49.1
49.1
6.82 52.4
43.4
6.95 57.6
32.6
7.01 52.4
52.4
6.94 53.9
49.2
6.95 58.8
36.0
7.03
125
TC
SHC
kW 40.9
40.9
7.36 45.5
34.9
7.64 50.6
27.0
7.67 43.4
43.4
7.58 46.8
38.2
7.64 51.7
28.9
7.68 45.4
45.4
7.63 47.7
41.3
7.64 52.3
30.4
7.69 48.3
48.3
7.64 49.0
46.7
7.65 53.3
33.6
7.71
See Legend and Notes on page 16.
