DS-RPC OWNER’S MANUAL
DETAILED OPERATION AND CONFIGURATION
__________________________________________________________________________________________
44
Toggle Auto Connect Port feature by
selecting #2, “Enable/Disable,” from the Auto
Connect Port menu followed by . The
DS71 or DS71-MD2 module displays the
current auto connect port status and asks if
you want to enable. Default Auto Connect
Port is disabled.
Auto Connect Port is ......................Disabled
Enable ? (Y/N, CR for no change):
Type “Y“ for yes followed by if you
want to enable Auto Connect Port. Type “N“
for no followed by if you want to disable
Auto Connect Port. Type for no change.
The DS71 or DS71-MD2 module stores Auto
Connect Port configuration in non-volatile
memory and returns to the Auto Connect Port
menu.
DCD LOGON/LOGOFF When enabled, DCD Logon/Logoff prevents
(DS71 only) unwanted modem connections by requiring
login before a modem connection is
established (DCD high). If a disconnection
occurs (DCD low), the DS-RPC will logoff.
If another connection is established (DCD
high), login will be required before
resuming normal operations.
IMPORTANT: This setting is crucial to the proper operation of
the Auto Connect Port and the Password Security functions. The
J-6 jumper must be in the forward (pin 1-2) position on the board.
The board comes from the factory in this condition. (See Appendix
D for the location of J6.) The EIA-232 port on the DS71 module
should be connected to the external modem via an RJ08X007
Crossed Pin Modular Cable and a 25MRJ45MD-6 MODEM
adapter. Do not move any other jumpers on the board.
