DS-RPC OWNER’S MANUAL
DETAILED OPERATION AND CONFIGURATION
__________________________________________________________________________________________
23
SELECTING A DEVICE There are two methods of selecting a device;
menu driven selection and ASCII character
string method.
Menu Driven From the main menu, select the number that
Selection
corresponds to the device you wish to
access, followed by . To return to the
main menu, send the attention character five
times (;;;;;).
ASCII Character Another method of selecting devices and
String operating the DS-RPC is the ASCII
character string method. To select a device
located on a peripheral module port, send
the port select code (default is $BT), the
module number, a comma, and then the port
number, followed by (there are no
spaces in the string). For example, to select
port 4 located on module 2, type
$BT2,4. To select port 1 on module 9
(DS9 model), type $BT9,1. To
disconnect, type $BT, then the attention
character.
To configure a module, type $BT and the
module number followed by , then
$CONFIG followed by . This will allow
access to the configuration menu for that
module. Once configuration is complete,
type X for “Exit” followed by . To
access the main menu, type the attention
character five times.
NOTE: You must exit main menu to send ASCII character string
commands.
NOTE: While operating using the ASCII Character String method,
consider placing the DS-RPC in binary mode.
