96” Allied Snowblower
ASSEMBLY INSTRUCTIONS – cont’d.
8. PTO SHIELD
All snowblowers are supplied with a PTO shield (#61). To install, remove
the two rear bolts at the top of the gearbox (#38). Bolt the PTO shield to
the gearbox by the hinges using these same bolts. A utility spring (#62)
keeps the shield in place. Hook one end of the spring in the hole in the
shield and the other end to the hole in the brace under the gearbox.
CAUTION: Do not run the snowblower without this shield in place.
REFILLING GEARBOX WITH OIL:
If the gearbox requires refilling with oil because of repairs to the gearbox,
add oil to the level shown in drawing. Check the level regularly using the
plug in the lid. The correct level is even with the bottom of the plug.
7
