PARTS LIST - VERTICAL SMOKER:
1 Smoker box with legs
3 Cooking grills
1 Water pan
1 Water pan bracket
1 Charcoal pan
1 Charcoal pan bracket
1 Chimney
1 Door handle with spring, washer
and cotter pin
1 Temperature gauge
4 Locking casters
1 Ash pan
ASSEMBLY INSTRUCTIONS
READ ALL SAFETY WARNINGS & ASSEMBLY INSTRUCTIONS CAREFULLY
BEFORE ASSEMBLING OR OPERATING YOUR SMOKER.
FOR MISSING PARTS, PLEASE CALL CUSTOMER SERVICE AT 1-800-527-0717.
(Proof of purchase will be required.)
Inspect contents of the box to ensure all parts are included and undamaged.
3
We recommend two people work together
when assembling this unit.
The following tool is required to assemble
this Vertical Smoker:
• Adjustable Wrench
1
2
3
4
5
6
7
8
9
10
11
2
3
4
5
6
7
9 8
10
11
1
