Hardware Installation
1. Be sure that your computer is turned off.
2. Connect the receiver to your computer. The receiver has a 2-head
connector for the keyboard and mouse connections (purple is for
the keyboard and green is for the mouse.) They also have pictures
on the top of the connector to identify them. Your computer
should either have the same color scheme or there will be a
picture next to the plug to identify it.
3. Install the batteries into your keyboard and mouse. Please make
sure you follow the picture on the inside compartment for the
batteries to make sure the batteries are installed correctly. Refer
to Fig. 1 and Fig. 2 below.
Fig. 1 Keyboard Bottom
Fig. 2 Mouse Bottom
Reset Button
Battery
Compartment
Reset Button Battery Compartment
