47
Section 8
1 04021-09 Nut, Elastic Stop 3/8-16
2 483088 Spring, SZC Pump Drive
3 43212 Sleeve
4 43674 Spacer, Pump Idler
5 04021-05 Nut, Center Lock 3/8-16
6 49922 Idler Arm Assembly, Pump Drive
7 04063-14 Key, 5 x 5 x 25mm
8 483164 Belt, Pump Drive SZC
9 483208 Pulley, Idler 3” Dia.
10 04043-04 Flatwasher, 3/8-.391 x .938 x .105 HD
11 482649 Pulley, 5.45 O.D. Tapered Bore
12 482085 Hub, Tapered, 15mm Bore
13 04001-45 Bolt, Hex Head 3/8-16 x 2”
14 43503 Pivot, Idler Short
15 48224 Bearing
16 04001-172 Bolt, Hex Head 1/4-20 x 1” Grade 8 Black
17 04001-62 Bolt, Hex Head 3/8-16 x 3-1/4”
18 04001-20 Bolt, Hex Head 3/8-16 x 1-1/2”
19 482968 Pulley, 5.45” Dia. 1” Bore
20 04001-31 Bolt, Hex Head 3/8-16 x 2-1/2”
21 04001-136 Bolt, Hex Head 3/8-16 x 1-1/4 Grade 8 Black
22 04019-04 Nut, Serr. Flange 3/8-16
23 04021-12 Nut, Center Lock 5/16-24
24 483123 Retainer, Pump Lever
25 424061 Control Lever, Pump
26 04043-04 Flatwasher, 3/8-.391 x .938 x .105
27 04021-09 Nut, Elastic Stop 3/8-16
28 483212 Pulley, Idler
Ref. Part
No. No.
Description
DRIVE SYSTEM COMPONENTS
