45
Section 8
SZC ROLL-OVER PROTECTION SYSTEM
1 483140 SZC ROPS
2 483150 Seat Belt, ROPS
3 04001-145 Bolt, Hex Head 1/2-13 x 3-1/2”
4 04040-13 Flatwasher, 1/2-.562 x 1.375 x .109
5 04021-19 Nut, Center Lock 1/2-13
6 481625-03 Thumb Screw, 5/16-18 NC x 3-4”
7 04062-06 Hair Pin, Cotter
8 483262 Pin
9 04021-19 Nut, Center Lock 1/2-13
10 424407 Bracket, Stop
11 04001-145 Bolt, Hex Head 1/2-13 x 3-1/2”
12 424400 Bracket, Seat Belt Hanger
13 04011-13 Screw, 1/4-20 x 3/4”
Ref. Part
No. No.
Description
