Page 23
19
Section 4
Figure 4-5 Adjusting Cutting Height
Figure 4-4 Deck Release Lever
DECK RELEASE
LEVER
HEIGHT ADJUSTMENT
PEDAL
4.14 Adjusting the Steering Levers
1. Position the seat to the desired location.
2. While in the operator's position with out the engine
running, move both steering levers forward and
reverse to check for full function control and
comfort.
3. If adjustment of the steering levers is needed, use the
following instructions to adjust.
A. Loosen the tension knob on the lever assembly.
B. Rotate the steering lever forward or backward to
achieve the optimum operating position.
C. Tighten the tension knob and repeat on the
opposite side.
D. While in the operators position, bring the steering
levers out of the neutral lock position and check
to make sure both levers are even before
operating.
4. The control handle can also be adjusted in two
different positions. If necessary, remove the two
bolts securing the control handle to the control lever.
Install the handle in the desired position.
Figure 4-6 Adjusting Steering Levers
TENSION
KNOB
ROTATE
LEVER
