FEATURES
• Foil shield and drain wire keep noise
out and intrinsic noise in.
• Meets or exceeds all standards for
Category 5 cable.
• Pinned and paired to EIA/TIA-568
specifications.
• Stranded riser version available in
custom lengths.
OVERVIEW
Regular unshielded twisted-pair (UTP) cable is fine for
most sites. It’s useful where the electronic-noise sources might
consist of a server or two, a laser printer, a few relatively
distant fluorescent lights, and somebody’s old desktop radio.
But you know that’s not going to work at your site. Maybe
you need to route your network cable next to an elevator, a
compressor, a belt-drive motor, or a big bank of fluorescents;
places where the electromagnetic and radio-frequency
interference (EMI/RFI) would wreak havoc with unshielded
cable.
Or maybe you need to run cable through Intensive Care,
or close to sensitive detection equipment. Unshielded cables
could themselves cause harmful interference in this
application.
Our Shielded Twisted-Pair (STP) cables are tailor-made for
these environments. The wires that carry data through these
cables are surrounded by a shielding layer of aluminum-
polyester foil that keeps outside noise out and intrinsic noise
in, along with a drain wire that diverts interference to
ground. Even the cable plugs are shielded!
These four-pair cables meet or exceed all Category 5
standards. They’re ready for 100-Mbps data traffic whenever
you are. And, though there is no definitive EIA/TIA standard
for STP cabling, these cables are also built, pinned, and paired
to match every part of the EIA/TIA-568 UTP specifications.
The stranded-conductor, riser-rated version (EVNSL60) is
available in several stock lengths and in custom lengths as
well.
The solid-conductor plenum-rated version (EVNSL71) is
available in a wider variety of stock lengths. Call for a quote
on a custom length. Keep in mind, large orders get a break
on price, so buy in quantity and save!
TYPICAL APPLICATION
Run 100BASE-T cable closer to factory floors, labs, or your
airport’s generators and X-ray machines than you thought
possible.
