SCHEMATIC WIRING DIAGRAM CDBC-APS/TS/TSR
29253 111103
EARLY MODELS
SOL
29257.0000B 12/99 ©1998 BUNN-O-MATIC CORPORATION
TANK HEATER
L1
GRN
GRN
RED-14 (MODEL 35)
WHI-14 (MODELS 15 & 20)
N L2
BLU-14
BLU-14
"KEEP WARM" HEATER
WHI
WHI
LIMIT
THERMOSTAT
WHI
WHI
WHI
WHI
SOL
REFILL
DISPENSE
J1-1
J1-2
J1-1
J1-5
J1-10
C
O
N
T
R
O
L
P
C
B
O
A
R
D
COM
N.O.
BLK
BLK
BLK
BLK-14
BLK-14 BLK-14
BLK
WHI/GRN
WHI/GRN
WHI/BLU
WHI/BLU
COUNTER
(OPTIONAL)
120V AC 2 WIRE
120/208V AC 3 WIRE
120/240V AC 3 WIRE
SINGLE PHASE
BLK
WHI
CONTROL PANEL ASSY
J2-1
J2-6
J2-11
BREW SW
ON/OFF SW
HIDDEN SW
J3-1
J3-4
BLK
PNK
WHI
GRN
LEVEL
PROBE
t °
STATIC
SHIELD
