2

LH 120 C Litronic Machine for Industrial Applications

Technical Data

Engine

Rating per ISO 9249

�������������

400 kW (543 HP) at 1,800 RPM

Model

�������������������������������

Liebherr D 9508

Type

��������������������������������

8 cylinder V-engine

Bore/Stroke

������������������

128/157 mm

Displacement

����������������

16.16 l

Engine operation

�����������������

4-stroke diesel

Common-rail-injection

turbo-charged

after-cooled

reduced emissions

Cooling

�����������������������������

water-cooled

Air cleaner

�������������������������

dry-type air cleaner with pre-cleaner, primary and

safety elements

Fuel tank

���������������������������

3,350 l

Electrical system

Voltage

�����������������������

24 V

Batteries

����������������������

4 x 170 Ah/12 V

Starter

������������������������

2 x 24 V/7.8 kW

Alternator

���������������������

three phase current 28 V/140 A

Option

������������������������������

Liebherr particle filter

Hydraulic System

Hydraulic system

�����������������

Positive Control multiple-circuit hydraulic system

Hydraulic pumps

for attachment and

travel drive

�������������������

4 Liebherr variable flow swash plate pumps

Max. flow

���������������������

4 x 309 l/min.

Max. hydr. pressure

��������

350 bar

Pump control

���������������������

electro-hydraulic with electronic engine speed

sensing regulation over entire RPM range,

pressure compensation, flow compensation

automatic oil flow optimizer, flow summation

Hydraulic pump

for swing drive

��������������

1 reversible swash plate pump, closed-loop

circuit

Max. flow

���������������������

483 l/min.

Max. hydr. pressure

��������

280 bar

Hydraulic tank

��������������������

1,240 l

Hydraulic system

�����������������

1,845 l

Hydraulic oil filter

�����������������

3 full flow filters in return line with integrated fine

filter area (5 µm), 1 high pressure filter for each

main pump

Cooler

������������������������������

radiator, consisting of cooling unit for coolant and

after-cooler as well as 2nd cooler for hydraulic oil

with hydrostatically regulated fan drive

MODE selection

������������������

adjustment of machine performance and the

hydraulics via a mode selector to match applica-

tion

RPM adjustment

�����������������

stepless adjustment of engine output via the rpm

at each selected mode

Hydraulic Controls

Power distribution

����������������

via control valves in single block with integrated

safety valves

Flow summation

������������

to boom stick and grapple

Closed-loop circuit

���������

for uppercarriage swing drive

Activation

��������������������������

electro-hydraulic control

Attachment and swing

�����

proportional via joystick levers

Travel

�������������������������

proportional via foot pedals or removable hand

levers

Additional functions

��������������

via joystick toggle switch or proportional via mini

joysticks

Swing Drive

Drive by

����������������������������

Liebherr swash plate motor with integrated brake

valves

Transmission

����������������������

Liebherr compact planetary reduction gear

Swing ring

�������������������������

Liebherr, sealed single race ball bearing swing

ring, internal teeth

Swing speed

����������������������

0 – 5.5 RPM stepless

Swing torque

����������������������

280 kNm

Holding brake

���������������������

wet multi-disc (spring applied, pressure released)

Option

������������������������������

switchable slewing gear (torque or RPM control)

Uppercarriage

Design

������������������������������

torque resistant modular design upper frame

Attachment mounting

�����������

parallel length girders

Catwalks

���������������������������

on both sides, possibility to get across on each

side

Operator’s Cab

Cab

���������������������������������

shape construction, resiliently mounted, sound

insulated, tinted windows, door with window,

sliding window left, headroom 2.0 m, roof, front

and bottom window armored glass, extra seat for

instructor

Operator’s seat

�������������������

Liebherr-Air-Comfort seat, air-suspended with

automatic weight adjustment, vertical and hori-

zontal seat damping including consoles and joy-

sticks. Seat and armrests adjustable separately

and in combination, seat heating as standard

Joysticks

���������������������������

arm consoles, swinging with the seat

Monitoring

�������������������������

large high resolution colour display with self-

explanatory operation via touch screen or turn-

push button, video capability, versatile adjusting,

control and monitoring facilities, e.g. climate con-

trol, implement and tool parameters

Heating system

�������������������

standard air conditioning, combined cooler/

heater, additional dust filter in fresh air/recircu-

lated

Noise emission

ISO 6396

���������������������������

L

pA

(inside cab)

= 70 dB(A)

2000/14/EC

�����������������������

L

WA

(surround noise) = 108 dB(A)

Undercarriage

EW

����������������������������������

heavy version, long undercarriage, extra wide

Drive

��������������������������������

Liebherr swash plate motors with integrated

brake valves on both sides

Transmission

����������������������

Liebherr planetary reduction gears

Travel speed

����������������������

low range – 1.7 km/h

high range – 3.9 km/h

Drawbar pull max.

����������������

516 kN

Track components

���������������

B 9 S, maintenance-free

Track rollers/Carrier rollers

�����

13/3

Track pads

������������������������

flat

Digging locks

���������������������

wet multi-discs (spring applied, pressure

released)

Brake valves

����������������������

integrated into travel motor

Attachment

Type

��������������������������������

high-strength steel plates at highlystressed points

for the toughest requirements. Complex and

stable mountings of attachment and cylinders.

Unrivalled strength, even at high loads

Hydraulic cylinders

���������������

Liebherr cylinders with special seal-system,

shock absorbed

Pivots

�������������������������������

sealed, low maintenance

Lubrication

������������������������

semi-automatic central lubrication system
