Shells for Loose Material
LH 120 C Litronic Machine for Industrial Applications
11
Variety of Tools
Shells for loose material with
cutting edge (without teeth)
Clamshell Model 25 B
Cutting width of shells
mm 1,700
1,700
2,000
1,800
Capacity
m
3
2.30
2.80
3.00
3.50
Weight
kg 3,200
3,250
3,550
3,300
Clamshell Model GMZ 50
Cutting width of shells
mm 1,400
1,600
1,800
2,000
2,200
2,400
Capacity
m
3
3.50
4.00
4.50
5.00
5.50
6.00
Weight
kg 2,950
3,100
3,250
3,400
3,550
3,700
Multiple
Tine Grapples
open tines
semi-closed tines
closed tines
Grapple Model 75 B (5 tines)
Capacity
m
3
2.00 2.50 3.00
2.00 2.50 3.00
2.00 2.50 3.00
Weight
kg 3,400 3,550 3,700
4,100 4,250 4,400
4,500 4,650 4,800
Grapple Model GMM 120-5 (5 tines)
Capacity
m
3
1.70 2.00 2.50 3.00 1.70 2.00 2.50 3.00 1.70 2.00 2.50 3.00
Weight
kg 2,475 2,525 2,595 2,660 2,765 2,830 2,945 3,065 2,950 3,145 3,300 3,465
Crane Hook with Suspension
Max. load
t 32
Weight
kg 180
Wood Grapples
GM 25 BH
GMH 50
Size
m
2
1,70
2,80
3,20
Width
mm 1.000
1.000
1.000
Opening width inside
mm 2.975
3.735
3.810
Opening width outside
mm 3.300
4.290
4.300
Overall height open
mm 3.085
2.225
2.265
Overall height closed
mm 3.815
2.680
2.735
Weight complete
kg 3.350
2.400
2.550
Electro Magnets with Suspension
Generator up to 30 kW
