R 984 C Litronic High Rise
Industrial Attachment
with Industrial-Type Gooseneck Boom 14,50 m
Attachment Envelope
Kinematic variant 3D
1 with industrial stick 12,50 m
2 with industrial stick 12,50 m and clamshell model 35
0 m
2
4
6
8
10
12
14
16
18
20
22
24
26
28
0 ft
10
20
30
40
50
60
70
80
90
0
-2
-4
2
4
6
8
0
-10
10
20
30
40
50
60
70
80
90
100
110
10
12
14
16
18
20
22
24
26
28
30
32
34
36
-6
-8
-20
m
ft
1
2
Operating Weight
and Ground Pressure
The operating weight includes basic machine with rigid cab elevation
and ballast weight 22 t, industrial-type gooseneck boom 14,50 m,
industrial stick 12,50 m and clamshell model 35/5,70 m
3
.
Undercarriage
HR
Pad width
mm 750
Weight
kg 209900
Ground pressure
on request
VarioLift
Plus
Kinematic Variant 3D:
Increased lift capacities below ground level
and when working at large outreach
Kinematic Variant 3C:
Altered range curve with additional reach
depth, e.g. for unloading from ships
Hole D
3D
Hole C
Hole 3
Version
3D
3D
3C
VarioLift
Plus
: Variable boom mounting positions for optimized lift capacities
with a
different working range
