R 984 C Litronic High Rise
Technical Data
Engine
Rating per ISO 9249
���������
504 kW (685 HP) at 1800 RPM
Model
�����������������������������
Cummins-QSK-19 C 750 according to level
IIIA / Tier 3
Type
�������������������������������
6 cylinder in-line engine
Bore/Stroke
����������������
159/159 mm
Displacement
�������������
18,9 l
Engine operation
��������������
4-stroke diesel
direct injection
turbo-charged
reduced emissions
Cooling
���������������������������
water-cooled
Air cleaner
�����������������������
dry-type air cleaner with pre-cleaner,
primary and safety elements, automatic
dust discharge
Fuel tank
�������������������������
1585 l
Standard
�������������������������
sensor controlled engine idling
Electrical system
Voltage
����������������������
24 V
Batteries
��������������������
2 x 144 Ah/12 V
Starter
�����������������������
24 V/9,0 kW
Alternator
�������������������
three phase current 24 V/100 A
Hydraulic System
Hydraulic pump
for attachment and
travel drive
�����������������
3 Liebherr variable flow, swash plate
pumps
Max. flow
�������������������
3 x 472 l/min.
Max. pressure
������������
350 bar
Pump regulation
���������������
electro-hydraulic with electronic engine
speed sensing regulation, pressure com-
pensation, automatic oil flow optimizer
Hydraulic pump
for swing drive
������������
reversible, variable flow, swash plate pump,
closed-loop circuit
Max. flow
�������������������
403 l/min.
Max. pressure
������������
340 bar
Hydraulic tank
������������������
880 l
Hydraulic system �������� 1760 l
Hydraulic oil filter
��������������
2 full flow filters in return line with inte-
grated fine filter area (5 μm), 1 high pres-
sure filter for each main pump
Cooler
�����������������������������
compact cooler, consisting of a water
cooler, sandwiched with hydraulic oil
cooler, aftercooler cores and air condi-
tioning, hydrostatically driven van
MODE selection
���������������
adjustment of machine performance and
the hydraulics via a mode selector to match
application
LIFT
���������������������������
for lifting
FINE
��������������������������
for precision work and lifting with sensitive
movements
ECO
��������������������������
for economical operation
POWER
���������������������
for maximum digging power and heavy
duty jobs
RPM adjustment
��������������
stepless adjustment of engine output via
rpm at each selected mode
Additional menu
���������������
4 adjustable oil flows, for optional accesso-
ries
Hydraulic Controls
Power distribution
������������
via control valves in single block with inte-
grated safety valves
Flow summation
���������
to boom stick and bucket cylinders
Closed-loop circuit
�����
for uppercarriage swing drive
Servo circuit
Attachment and
swing
������������������������
proportional via joystick levers
Travel
������������������������
proportional via foot pedals or removable
hand levers
Additional functions
����������
via foot pedals or joystick toggle switch
Swing Drive
Drive by
���������������������������
Liebherr swash plate motor
Transmission
�������������������
Liebherr compact planetary reduction gear
Swing ring
�����������������������
Liebherr, sealed single race ball bearing
swing ring, internal teeth
Swing speed
��������������������
0 – 5,2 RPM stepless
Swing torque
�������������������
390 kNm
Holding brake
������������������
wet multi-disc (spring applied, pressure
released)
Option
�����������������������������
pedal controlled positioning brake
Uppercarriage
Design
����������������������������
torque resistant modular design upper
frame
Attachment mounting
�������
parallel length girders
Catwalks
�������������������������
on both sides, possibility to get across on
each side, descend on undercarriage in
every upper carriage position possible
Operator’s Cab
Cab
��������������������������������
profiles and deep drawn technology, resil-
iently mounted, sound insulated, tinted
windows. Front window armored glass,
door with sliding window
Operator’s seat
����������������
shock absorbing suspension, adjustable to
operator’s weight, 6-way adjustable seat
with mountable head rest
Joysticks
�������������������������
integrated into adjustable seat consoles
Monitoring
�����������������������
menu driven query of current operating
conditions via the LCD display. Automatic
monitoring, display, warning (acoustical
and optical signal) and saving machine
malfunction data, for example, engine over-
heating, low engine oil pressure or low
hydraulic oil level
Heating system
����������������
standard automatic air conditioning, com-
bined cooler/heater, additional dust filter in
fresh air/recirculated
Noise emission
ISO 6396
�������������������������
L
pA
(inside cab) = 74 dB(A)
Undercarriage
Version HD
����������������������
heavy duty
Drive
�������������������������������
Liebherr swash plate motor
Transmission
�������������������
Liebherr planetary reduction gears
Travel speed
��������������������
0 – 2,3 km/h
Drawbar pull max.
������������
735 kN
Track components
�����������
track pitch 280 mm, maintenance-free
Track rollers/
Carrier rollers
�������������������
15/4
Track pads
����������������������
flat track pads
Digging locks
�������������������
wet multi-discs (spring applied, pressure
released)
Brake valves
��������������������
integrated in main valve block
Attachment
Type
�������������������������������
high-strength steel plates at highly-
stressed points for the toughest require-
ments. Complex and stable mountings of
attachment and cylinders. Unrivalled
strength, even at high loads
Hydraulic cylinders
�����������
Liebherr cylinders with special seal system,
shock absorbed
Pivots
������������������������������
sealed, low maintenance
Lubrication
����������������������
automatic lubrication system Lincoln
“Centromatic” for attachment and swing
ring
