16
R 9800
Technical Data
Engine
2 Cummins diesel engine
Rating per
SAE J 1995
����������������
2 x 1.492 kW/2 x 2,000 HP at 1,800 rpm
Model
������������������������
Cummins QSK60
(USA/EPA Tier 2 or fuel consumption
optimized setting)
Type
��������������������������
16 cylinder V-engine
Displacement
�������������
60 l/3,661 in
3
Bore/Stroke
����������������
159/190 mm / 6.26/7.48 in
or
2 MTU diesel engine
Rating per ISO 3046
����
2 x 1.425 kW/2 x 1,910 HP at 1,800 rpm
Model
������������������������
12V4000 (USA/EPA Tier 2)
Type
��������������������������
12 cylinder V-engine
Displacement
�������������
57,2 l/3,490 in
3
Bore /Stroke
���������������
170/210 mm / 6.69/8.26 in
Engine cooling system
������
fans driven via hydraulic piston motors
Air cleaner
�����������������������
dry-type air cleaner with pre-cleaner,
automatic dust ejector, primary and safety
elements
Fuel tank
�������������������������
17.597 l/4,649 gal
Fuel filtration
��������������������
2 stage fuel filtration with water separator
and electric priming pump
Engine lubrication
�������������
pre-lube starting system
ELIMINATOR™ engine oil automatic
filtration system (Cummins) + centrifugal
filtration
engine oil automatic filtration system (MTU)
+ centrifugal filtration
Electrical system
Voltage
����������������������
24 V
Batteries
��������������������
8 x 170 Ah/12 V (Cummins)/
12 x 170 Ah/12 V (MTU) starting battery
4 x 170 Ah/12 V service systems
Alternator
�������������������
2 x 24 V/260 Amp (brushless)
Engine idling
��������������������
electronically controlled
Electronic engine
power management
����������
engine power and speed sensing over the
entire engine rpm range
Hydraulic System
Attachment and travel drive
Hydraulic pumps
��������
10 variable flow axial piston pumps
Max. flow
�������������������
10 x 750 l/min. / 10 x 198 gpm
Max. hydr. pressure
����
320 bar/4,641 psi
Swing drive
Hydraulic pumps
��������
4 reversible swash plate pumps,
closedloop circuit
Max. flow
�������������������
4 x 535 l/min. / 4 x 141 gpm
Max. hydr. pressure
����
320 bar/4,641 psi
Pump management
����������
electronically controlled pressure and flow
management with oil flow optimisation
Hydraulic tank capacity
�����
5.800 l/1,532 gal
Hydraulic system
capacity
��������������������������
10.000 l/2,642 gal
Hydraulic oil filter
��������������
1 high pressure safety filter after each high
pressure pump + fine filtration of entire
return flow (15/5 μm)
Hydraulic oil cooler
�����������
4 separate coolers, 4 temperature
controlled fans driven via hydraulic piston
motors
Main pump protection
�������
automatic protection against low oil level
Electro-Hydraulic Controls
Servo circuit
��������������������
independent, electronic over hydraulic
proportional controls of each function
Emergency control
������������
emergency lowering of the attachment to
the ground
Power distribution
������������
via monoblock control valves with inte-
grated primary relief valves and flanged on
secondary valves for travel and with inte-
grated proportional and safety valves
Flow summation
���������������
to attachment and travel drive
Electro-hydraulic servo control
Attachment and
swing
������������������������
electronic optimized control via
proportional valves
Travel
�����������������������
electronic optimized control via
proportional valves
Electronic damping
system
����������������������������
Liebherr designed electronic control of
cylinder end-position
Electric System
Electric isolation
���������������
easy accessible battery isolations
Working lights
������������������
LED lights:
– 4 on working attachment
– 4 on RHS of uppercarriage
– 4 on LHS of uppercarriage
– 2 on counterweight
– 2 on cab
Emergency stop switches
��
at ground level, in hydraulic compartment,
in engine and pumps compartment and in
operator cab
Electrical wiring
����������������
heavy duty execution in IP 65 standard for
operating conditions of – 50 °C to 100 °C/
– 58 °F to 212 °F
Swing Drive
Hydraulic motor
����������������
4 Liebherr axial piston motors
Swing gear
����������������������
4 Liebherr planetary reduction gears
Swing ring
�����������������������
Liebherr, sealed triple roller swing ring,
internal teeth
Swing speed
��������������������
0 – 3.6 rpm
Swing-holding brake
���������
4 hydraulically released, maintenance-free,
external multi-disc brakes
Uppercarriage
Design
����������������������������
torsion resistant designed upper frame in
box type structure for superior strength and
durability
Attachment mounting
�������
parallel longitudinal main girders in
box-section structure
Machine access
���������������
45° access system with handrails on the
cab side of the uppercarriage. Full con-
trolled descent in case of emergency stop.
Additional emergency ladder fitted near the
cab
Electric Motor (optional)
2 electric motors
Power output
�������������������
2 x 1.700 kW/2,280 HP
Type
�������������������������������
3 phase AC squirrel cage motor
Voltage
����������������������������
6,600 V, other voltage on request
Frequency
�����������������������
50 Hz (or 60 Hz)
Revolutions
����������������������
1,500 rpm or 1,800 rpm
Motor cooling
������������������
integrated air-to-air heat exchanger
Starting method
���������������
inrush current limited to 2,2 full load current
Starting sequence
������������
successive startup of electric motors
