Liebherr ICP 3314 Comfort - Manual (Page 8)

w During adjustment the value flashes on the display.
w The new setting is adopted approx. 5 seconds after the last
time the button was pressed and the set temperature
displayed again. The temperature in the interior gradually
adjusts to the new value.
5.4.5 SuperFrost
With this function you can freeze fresh food quickly
through to the core. The appliance operates with
maximum refrigeration. The noise of the refrigeration
unit may be temporarily louder as a result.
In addition, frozen food already in storage is given a “cold
reserve”. The food stays frozen longer as a result when you
defrost the appliance.
The maximum amount of fresh food which can be frozen in 24
h is indicated on the type plate under “freezing capacity ... kg/
24h”. This amount varies according to the model and climate
rating.
You have to activate SuperFrost in good time, depending on
how much fresh food is to be frozen: about 6 hours before
placing the food inside in case of small amounts and about 24
hours in advance in case of the maximum amount of food to be
frozen.
Wrap produce and spread it out as far as possible. Do not
allow produce to be frozen to touch produce that is already
frozen to prevent the latter thawing.
You do not have to activate SuperFrost in the following cases:
- when placing frozen food in the freezer
- when freezing up to approx. 1 kg fresh food daily
Freezing with SuperFrost
u
Briefly press the SuperFrost button Fig. 2 (11) once.
w The SuperFrost symbol Fig. 2 (12) shines.
w The freezing temperature drops, the appliance operates with
the maximum cooling capacity.
For a smaller quantity of produce to be frozen:
u wait approx. 6 h.
u Place wrapped produce in the bottom drawers.
For the maximum quantity of produce to be frozen:
u wait approx. 24 h.
u Remove bottom drawer and place produce directly in the
appliance so that it touches the base or sides.
w SuperFrost is automatically deactivated after 65 hours.
w The SuperFrost symbol Fig. 2 (12) extinguishes once
freezing is completed.
u Place produce in the drawer and then push the drawer back
in again.
w The appliance continues to operate in the energy-saving,
normal mode.
5.4.6 Drawers
Note
The energy consumption increases and the cooling perform-
ance decreases if there is insufficient ventilation.
For appliances with NoFrost:
u Leave the bottom drawer in the appliance!
u Always keep the air slits of the fan free at the rear wall!
u To store frozen food directly on the shelves: pull the drawer
forwards and lift it out.
5.4.7 Shelves
u To remove the shelf: lift up
at the front and pull out.
u To put the shelf back: simply
push in as far as it will go.
5.4.8 VarioSpace
Apart from being able to
remove the drawers, you can
also remove the shelves,
creating space for large items
of frozen food. Poultry, meat,
large pieces of game and high
bakery products can be frozen
in one piece and prepared.
u The maximum load of frozen
food for the drawers is 25 kg
each and for the shelves
35 kg each.
6 Maintenance
6.1 Manual defrosting
The refrigerator compartment is defrosted automatically.
The defrost water evaporates as a result of the heat of the
compressor. Drops of water on the rear wall are perfectly
normal.
u Regularly clean the drain opening to allow the water to flow
away (see 6.2) .
A layer of frost or ice can build up in the freezer compartment
after a long period of operation.
The layer of frost or ice builds up faster if the appliance is
opened often or if the food is warm when placed inside.
However, a thick layer of ice will increase the appliance‘s
energy consumption. You should therefore defrost the appli-
ance regularly.
CAUTION
Risk of injury and damage as a result of hot steam!
u Do not use electric heaters or steam cleaners, naked flames
or defrosting sprays for defrosting.
u Do not remove ice using sharp instruments.
u Switch on SuperFrost one day before defrosting.
w The frozen goods are provided with a “cold reserve”.
u Switch off the appliance.
w The temperature display goes out.
w If the temperature display does not go out, the child lock
function (see 5.1) is active.
u Pull out the power plug or switch off the fuse.
u If possible, put the frozen goods in the freezer drawer,
wrapped in newspaper or a blanket, and store in a cool
place.
u Place a pan with hot, not boiling
water on a middle shelf.
-or-
u Half-fill the two lower drawers with
lukewarm water and put them in the
appliance.
w Defrosting is speeded up.
w Defrost water is collected in the drawers.
u Leave the door of the appliance open while defrosting.
Maintenance
8 * Depending on model and options
