- F0 to F9
-
The power failure symbol flashes.
4 Putting into operation
4.1 Switching on the appliance
Note
u The refrigerator compartment is switched on automatically
when the freezer compartment is switched on.
4.1.1 Switch on the freezer compartment
The appliance should have been operating for about
4 hours before you stock it with frozen food. Only
place frozen goods in the freeze compartment once
it is cold.
u Open the door.
u Press freezer compartment On/Off button Fig. 2 (8) .
w The temperature displays light up. The interior light goes on
when the refrigerator compartment door is opened. Refriger-
ator and freezer compartments are switched on.
w If “DEMO” is displayed, demo mode is activated. Please
contact the after sales service.
4.1.2 Switch on refrigerator compartment
If the refrigerator compartment was switched off (e.g. during an
extended absence like holidays), it can be switched back on
separately.
u Open the door.
u Press the refrigerator compartment On/Off button Fig. 2 (1) .
w The temperature displays light up. The interior light goes on
when the refrigerator compartment door is opened. The
refrigerator compartment is switched on again.
5 Control
5.1 Child proofing
The child-proofing function enables you to make
sure that the appliance is not inadvertently switched
off by playing children.
5.1.1 Setting the child lock
To switch on the function:
u Activate setting mode: press the SuperFrost button
Fig. 2 (11) for approx. 5 seconds.
w The Menu symbol Fig. 2 (15) is shown on the display.
w c flashes on the display.
u Briefly confirm with the SuperFrost button, Fig. 2 (11) .
w c1 appears in the display.
u Briefly confirm with the SuperFrost button, Fig. 2 (11) .
w The child lock symbol Fig. 2 (16) , lights up on the
display.
w c flashes on the display.
w The child lock function is switched on.
If setting mode is to be terminated:
u Briefly press the freezer compartment On/Off button
Fig. 2 (8) .
-or-
u Wait for 5 minutes.
w The temperature display shows the temperature again.
To switch off the function:
u Activate setting mode: press the SuperFrost button
Fig. 2 (11) for approx. 5 seconds.
w The Menu symbol Fig. 2 (15) is shown on the display.
w c flashes on the display.
u Briefly confirm with the SuperFrost button, Fig. 2 (11) .
w c0 appears in the display.
u Briefly confirm with the SuperFrost button, Fig. 2 (11) .
w The child lock symbol Fig. 2 (16) goes out.
w c flashes on the display.
w The child lock function is switched off.
If setting mode is to be terminated:
u Briefly press the freezer compartment On/Off button
Fig. 2 (8) .
-or-
u Wait for 5 minutes.
w The temperature display shows the temperature again.
5.2 Temperature alarm
The audible alarm sounds if the freezer temperature
is not cold enough.
The temperature display and the alarm symbol
Fig. 2 (14) flash at the same time.
The cause of the temperature being too high may be:
- warm fresh food was placed inside
- too much warm ambient air flowed in when rearranging and
removing food
- power failure for some time
- the appliance is faulty
The audible alarm is automatically silenced, the alarm symbol
Fig. 2 (14) goes out and the temperature display stops flashing
when the temperature is sufficiently cold again.
If the alarm status persists: (see Malfunction).
Note
Food may be spoilt if the temperature is not cold enough.
u Check the quality of the food. Do not consume spoiled food.
5.2.1 Muting the temperature alarm
The audible alarm can be muted. When the temperature is
sufficiently cold again, the alarm function is active again.
u Press alarm button Fig. 2 (13) .
w The audible alarm is silenced.
5.3 Refrigerator compartment
The natural circulation of air in the refrigerator compartment
results in zones differing in temperature. It is coldest directly
above the vegetable drawers and at the rear wall. It is warmest
at the top front of the compartment and in the door.
5.3.1 Food refrigeration
Note*
The energy consumption increases and the cooling perform-
ance decreases if the ventilation is inadequate.
u Always keep the air slits of the fan free.
u Store perishable food such as ready-to-serve dishes, meat
products and sausages in the coldest zone. Place butter
and preserves in the upper area and in the door (see Appli-
ance at a glance).
u Use recyclable plastic, metal, aluminium and glass
containers and cling film for wrapping.
u Always store liquids and food which is subject to odour or
taste transfer in closed containers or cover them.
Putting into operation
* Depending on model and options 5
