Lift Capacities
with Industrial-Type Straight Boom 14.00 m
R 974 C Litronic High Rise 9
Height Can be slewed through 360° In longitudinal position of undercarriage Max. reach * Limited by hydr. capacity
The lift capacities are stated in metric tonnes (t) on the lifting gear’s stick tip, and can be lifted 360° on firm, level supporting surface. Capacities
are valid for 750 mm flat pads. Indicated loads are based on ISO 10567 standard and do not exceed 75 % of tipping or 87 % of hydraulic capacity
(indicated via *). Lifting capacity of the excavator is limited by machine stability, hydraulic capacity and maximum permissible load of the load
hook.
According to European Standard, EN 474-5: In the European Union excavators have to be equipped with an overload warning device, a load dia-
gram and automatic check valves on the hoist cylinders, when they are used for lifting operations which require the use of lifting accessories.
Industrial Stick 10.50 m
4.5 m 6.0 m 7.5 m 9.0 m 10.5 m 12.0 m 13.5 m 15.0 m 16.5 m 18.0 m 19.5 m 21.0 m 22.5 m 24.0 m 25.5 m
Under-
m carriage m
28.5 HR
27.0 HR
25.5 HR
24.0 HR
22.5 HR
21.0 HR
19.5 HR
18.0 HR
16.5 HR
15.0 HR
13.5 HR
12.0 HR
10.5 HR
9.0 HR
7.5 HR
6.0 HR
4.5 HR
3.0 HR
1.5 HR
0 HR
– 1.5 HR
– 3.0 HR
– 4.5 HR
– 6.0 HR
– 7.5 HR
– 9.0 HR
– 10.5 HR
11.6* 11.6* 11.83
11.9* 11.9* 10.1* 10.1* 14.27
12.2* 12.2* 11.5* 11.5* 9.1* 9.1* 16.20
11.2* 11.2* 10.7* 10.7* 8.5* 8.5* 17.78
11.0* 11.0* 10.4* 10.4* 10.0* 10.0* 8.1* 8.1* 19.12
10.9* 10.9* 10.3* 10.3* 9.8* 9.8* 9.5* 9.5* 7.7* 7.7* 20.24
10.9* 10.9* 10.3* 10.3* 9.8* 9.8* 9.3* 9.3* 8.2* 8.2* 7.5* 7.5* 21.20
11.0* 11.0* 10.3* 10.3* 9.8* 9.8* 9.3* 9.3* 8.9* 8.9* 7.3* 7.3* 22.01
12.0* 12.0* 11.1* 11.1* 10.4* 10.4* 9.9* 9.9* 9.3* 9.3* 8.9* 8.9* 8.0* 8.0* 7.1* 7.1* 22.70
12.3* 12.3* 11.4* 11.4* 10.6* 10.6* 10.0* 10.0* 9.4* 9.4* 8.9* 8.9* 8.5* 8.5* 7.1* 7.1* 23.26
13.9* 13.9* 12.7* 12.7* 11.7* 11.7* 10.8* 10.8* 10.1* 10.1* 9.5* 9.5* 9.0* 9.0* 8.5* 8.5* 7.0* 7.0* 23.71
16.4* 16.4* 14.6* 14.6* 13.2* 13.2* 12.0* 12.0* 11.1* 11.1* 10.3* 10.3* 9.7* 9.7* 9.1* 9.1* 8.6* 8.6* 7.3* 7.3* 7.0* 7.0* 24.06
24.2* 24.2* 20.2* 20.2* 17.3* 17.3* 15.3* 15.3* 13.7* 13.7* 12.4* 12.4* 11.4* 11.4* 10.5* 10.5* 9.8* 9.8* 9.2* 9.2* 8.6* 8.6* 8.1* 8.1* 7.0* 7.0* 24.30
26.5* 26.5* 21.6* 21.6* 18.3* 18.3* 16.0* 16.0* 14.2* 14.2* 12.8* 12.8* 11.7* 11.7* 10.7* 10.7* 9.9* 9.9* 9.3* 9.3* 8.6* 8.6* 8.0* 8.0* 7.1* 7.1* 24.46
16.5* 16.5* 22.9* 22.9* 19.3* 19.3* 16.6* 16.6* 14.7* 14.7* 13.2* 13.2* 11.9* 11.9* 10.9* 10.9* 10.1* 10.1* 9.3* 9.3* 8.7* 8.7* 8.0* 8.0* 7.2* 7.2* 24.51
8.8* 8.8* 24.0* 24.0* 20.0* 20.0* 17.2* 17.2* 15.1* 15.1* 13.5* 13.5* 12.2* 12.2* 11.1* 11.1* 10.2* 10.2* 9.4* 9.4* 8.7* 8.7* 7.9* 7.9* 7.3* 7.3* 24.48
7.3* 7.3* 16.9* 16.9* 20.6* 20.6* 17.7* 17.7* 15.4* 15.4* 13.7* 13.7* 12.3* 12.3* 11.2* 11.2* 10.2* 10.2* 9.4* 9.4* 8.6* 8.6* 7.7* 7.7* 7.5* 7.5* 24.35
3.5* 3.5* 7.5* 7.5* 14.5* 14.5* 20.9* 20.9* 17.9* 17.9* 15.6* 15.6* 13.9* 13.9* 12.4* 12.4* 11.3* 11.3* 10.2* 10.2* 9.3* 9.3* 8.5* 8.5* 7.4* 7.4* 7.3* 7.3* 24.12
2.8* 2.8* 5.0* 5.0* 8.4* 8.4* 14.1* 14.1* 20.9* 20.9* 18.0* 18.0* 15.7* 15.7* 13.9* 13.9* 12.4* 12.4* 11.2* 11.2* 10.2* 10.2* 9.2* 9.2* 8.2* 8.2* 7.2* 7.2* 23.79
6.5* 6.5* 9.6* 9.6* 14.6* 14.6* 20.6* 20.6* 17.8* 17.8* 15.6* 15.6* 13.8* 13.8* 12.3* 12.3* 11.1* 11.1* 10.0* 10.0* 8.9* 8.9* 7.8* 7.8* 6.9* 6.9* 23.36
8.1* 8.1* 11.0* 11.0* 15.6* 15.6* 19.9* 19.9* 17.3* 17.3* 15.2* 15.2* 13.5* 13.5* 12.0* 12.0* 10.8* 10.8* 9.6* 9.6* 8.5* 8.5* 7.1* 7.1* 6.7* 6.7* 22.83
12.5* 12.5* 17.0* 17.0* 19.0* 19.0* 16.6* 16.6* 14.6* 14.6* 13.0* 13.0* 11.5* 11.5* 10.2* 10.2* 9.0* 9.0* 7.7* 7.7* 7.1* 7.1* 21.62
18.6* 18.6* 17.6* 17.6* 15.5* 15.5* 13.7* 13.7* 12.2* 12.2* 10.8* 10.8* 9.4* 9.4* 8.1* 8.1* 7.9* 7.9* 19.71
12.5* 12.5* 11.0* 11.0* 10.8* 10.8* 15.24
