Lift Capacities
with Industrial-Type Straight Boom 12.00 m
R 974 C Litronic High Rise 5
Height Can be slewed through 360° In longitudinal position of undercarriage Max. reach * Limited by hydr. capacity
The lift capacities are stated in metric tonnes (t) on the lifting gear’s stick tip, and can be lifted 360° on firm, level supporting surface. Capacities
are valid for 750 mm flat pads. Indicated loads are based on ISO 10567 standard and do not exceed 75 % of tipping or 87 % of hydraulic capacity
(indicated via *). Lifting capacity of the excavator is limited by machine stability, hydraulic capacity and maximum permissible load of the load
hook.
According to European Standard, EN 474-5: In the European Union excavators have to be equipped with an overload warning device, a load dia-
gram and automatic check valves on the hoist cylinders, when they are used for lifting operations which require the use of lifting accessories.
Industrial Stick 9.00 m
4.5 m 6.0 m 7.5 m 9.0 m 10.5 m 12.0 m 13.5 m 15.0 m 16.5 m 18.0 m 19.5 m 21.0 m 22.5 m 24.0 m 25.5 m
Under-
m carriage m
28.5 HR
27.0 HR
25.5 HR
24.0 HR
22.5 HR
21.0 HR
19.5 HR
18.0 HR
16.5 HR
15.0 HR
13.5 HR
12.0 HR
10.5 HR
9.0 HR
7.5 HR
6.0 HR
4.5 HR
3.0 HR
1.5 HR
0 HR
– 1.5 HR
– 3.0 HR
– 4.5 HR
– 6.0 HR
– 7.5 HR
– 9.0 HR
– 10.5 HR
13.9* 13.9* 10.17
13.8* 13.8* 11.9* 11.9* 12.58
14.9* 14.9* 13.7* 13.7* 10.8* 10.8* 14.41
13.8* 13.8* 13.1* 13.1* 10.0* 10.0* 15.89
13.5* 13.5* 13.0* 13.0* 11.9* 11.9* 9.5* 9.5* 17.10
13.5* 13.5* 12.9* 12.9* 12.4* 12.4* 9.7* 9.7* 9.1* 9.1* 18.11
14.4* 14.4* 13.6* 13.6* 13.0* 13.0* 12.4* 12.4* 12.0* 12.0* 8.9* 8.9* 18.93
14.8* 14.8* 13.9* 13.9* 13.1* 13.1* 12.5* 12.5* 12.0* 12.0* 9.3* 9.3* 8.7* 8.7* 19.61
16.8* 16.8* 15.4* 15.4* 14.3* 14.3* 13.4* 13.4* 12.7* 12.7* 12.0* 12.0* 11.5* 11.5* 8.6* 8.6* 20.14
19.9* 19.9* 17.8* 17.8* 16.1* 16.1* 14.8* 14.8* 13.8* 13.8* 12.9* 12.9* 12.2* 12.2* 11.6* 11.6* 8.5* 8.5* 20.55
25.4* 25.4* 21.6* 21.6* 19.0* 19.0* 17.0* 17.0* 15.4* 15.4* 14.2* 14.2* 13.2* 13.2* 12.4* 12.4* 11.6* 11.6* 8.6* 8.6* 20.84
36.2* 36.2* 28.3* 28.3* 23.5* 23.5* 20.2* 20.2* 17.9* 17.9* 16.1* 16.1* 14.7* 14.7* 13.5* 13.5* 12.6* 12.6* 11.7* 11.7* 8.8* 8.8* 8.6* 8.6* 21.02
31.0* 31.0* 25.3* 25.3* 21.4* 21.4* 18.7* 18.7* 16.7* 16.7* 15.1* 15.1* 13.8* 13.8* 12.7* 12.7* 11.8* 11.8* 9.4* 9.4* 8.8* 8.8* 21.09
22.0* 22.0* 26.7* 26.7* 22.5* 22.5* 19.5* 19.5* 17.2* 17.2* 15.5* 15.5* 14.1* 14.1* 12.9* 12.9* 11.8* 11.8* 9.3* 9.3* 8.9* 8.9* 21.04
6.4* 6.4* 15.8* 15.8* 27.7* 27.7* 23.2* 23.2* 20.0* 20.0* 17.6* 17.6* 15.7* 15.7* 14.2* 14.2* 12.9* 12.9* 11.7* 11.7* 9.2* 9.2* 20.89
3.6* 3.6* 7.6* 7.6* 14.8* 14.8* 28.1* 28.1* 23.6* 23.6* 20.4* 20.4* 17.9* 17.9* 15.9* 15.9* 14.3* 14.3* 12.9* 12.9* 11.5* 11.5* 9.5* 9.5* 20.62
5.9* 5.9* 9.4* 9.4* 15.4* 15.4* 27.4* 27.4* 23.7* 23.7* 20.4* 20.4* 17.9* 17.9* 15.8* 15.8* 14.1* 14.1* 12.6* 12.6* 11.0* 11.0* 10.0* 10.0* 20.24
11.4* 11.4* 16.8* 16.8* 27.2* 27.2* 23.2* 23.2* 20.1* 20.1* 17.6* 17.6* 15.5* 15.5* 13.7* 13.7* 12.1* 12.1* 10.1* 10.1* 9.7* 9.7* 19.73
13.5* 13.5* 18.7* 18.7* 26.0* 26.0* 22.3* 22.3* 19.3* 19.3* 16.9* 16.9* 14.9* 14.9* 13.0* 13.0* 11.1* 11.1* 10.1* 10.1* 18.63
24.1* 24.1* 20.8* 20.8* 18.1* 18.1* 15.8* 15.8* 13.8* 13.8* 11.7* 11.7* 11.6* 11.6* 16.64
