Liebherr LTR 1100 - Manual (Page 7)

1500
1000
(1200)
8200 (8400)
R = 8000
S1900
2740
8680
1400
34
10
8950
6413
5360
34
90
R =
4420
R = 4795
13141
4191
35
00
50
50
LTR 1100 7
Fast and economical ballasting
of the central ballast and slewing
platform ballast by self assembly.
• Max ballast of slewing
platform 32 tons
• Central ballast 15 t
Modern crane cab
The backwards tiltable crane cab offer a comfortable and functional working
place. The control elements and displays are arranged according to ergonomet-
ric factors. Thus a safe and fatigue-proof working is assured.
Fast and safe erection
The mounting of the additional equipment and the counterweight are designed
for speed, safety and comfort. For the safety of the operators pedestals and
hand holds are provided.
Comfort and functionality
