Liebherr KP 2620 Comfort - Manual (Page 10)

6.3 Replacing the interior illumination
with LED lamp
In the device, an LED lamp is used as standard illumination for
the interior space.
When an incandescent bulb is used:
q
Use an incandescent lamp with max. 25 W and E14 socket.
q
Power supply (AC) and voltage at the operating point must
comply with the details on the rating plate (see Appliance at
a glance).
When a LED is used:
q
Use only the original LED lamp from the manufacturer. The
lamp can be obtained through customer service or a
specialist dealer (see 6.4) .
WARNING
Risk of injury from LED light!
The light intensity of the LED lighting corresponds to laser
class 1/1M.
If the cover is removed:
u Do not look directly into the light at close quarters through
optical lenses. Doing so may damage your eyes.
WARNING
Fire hazard from the LED light!
If different LED lights are used, there is a danger of overheating
or fire.
u Use the manufacturer's original LED light.
u Switch off the appliance.
u Pull out the mains plug or switch off/unscrew the fuse.
u Take hold of the lamp cover at
the top and bottom Fig. 14 (1) .
u Disengage the lamp cover at
the back and detach it
Fig. 14 (2) .
u Replace the lamp Fig. 14 (3) .
u Clip the back end of the cover
in and clip the sides into place.
Fig. 14
6.4 Customer service
First check whether you can correct the fault yourself by refer-
ence to the list (see Malfunction). If this is not the case, please
contact the customer service whose address is given in the
enclosed customer service list.
WARNING
Risk of injury if repair work is not carried out professionally!
u Have any repairs and action - not expressly specified - on
the appliance and mains cable carried out by service
personnel only. (see Maintenance)
u Read the appliance
designation
Fig. 15 (1) , service
No. Fig. 15 (2) and
serial No. Fig. 15 (3)
off the type plate
located inside the
appliance on the left-
hand side.
Fig. 15
u Notify the customer service, specifying the fault, appliance
designation Fig. 15 (1) , service No. Fig. 15 (2) and serial No.
Fig. 15 (3) .
w This will help us to provide you with a faster and more accu-
rate service.
u Keep the appliance closed until the customer service
arrives.
w The food will stay cool longer.
u Pull out the mains plug (not by pulling the connecting cable)
or switch off the fuse.
7 Malfunction
Your appliance is designed and manufactured for a long life
span and reliable operation. If a malfunction nonetheless
occurs during operation, check whether it is due to a handling
error. In this case you will have to be charged for the costs
incurred, even during the warranty period. You may be able to
rectify the following faults yourself:
Appliance does not work.
→ The appliance is not switched on.
u Switch on the appliance.
→ The power plug is not properly inserted in the wall socket.
u Check power plug.
→ The fuse of the wall socket is not in order.
u Check fuse.
The compressor runs for a long time.
→ The compressor switches to a low speed when little cold is
needed. Although the running time is increased as a result,
energy is saved.
u This is normal in energy-saving models.
→ SuperCool is activated.
u The compressor runs for longer in order to rapidly cool the
food. This is normal.
A LED on the bottom rear of the appliance (at the
compressor) flashes regularly every 15 seconds*.
→ The inverter is equipped with a diagnostic LED.
u The flashing is normal.
Excessive noise.
→ Due to the various speed steps, speed-regulated*
compressors can generate different running noises.
u The sound is normal.
A bubbling and gurgling noise.
→ This noise comes from the refrigerant flowing in the refriger-
ation circuit.
u The sound is normal.
A quiet clicking noise.
→ The noise is produced whenever the refrigeration unit
(motor) automatically switches on or off.
u The sound is normal.
A hum. It is briefly a little louder when the refrigeration
unit (the motor) switches on.
→ The refrigeration increases automatically when the Super-
Cool function is activated, fresh food has just been placed
in the appliance or the door has been left open for a while.
u The sound is normal.
Malfunction
10 * Depending on model and options
