Lift chart - fixed jib, Main boom 66 ft, Main boom 152 ft – Liebherr HS 895 HD Litronic User Manual
Page 14: Main boom 229 ft, Main boom 94 ft, Main boom 181 ft, Main boom 248 ft, Main boom 123 ft, Main boom 209 ft, Main boom 258 ft
Capacities in 1000 lbs with fixed jib (No. 0806.xx) 166,000 lbs counterweight + 59,500 lbs carbody counterweight. Above lift chart is for reference only.
For actual lift duty please refer to lift chart in operator’s cab or manual.
Lift chart - fixed jib
(No. 0806.xx)
Offset 15°
14 HS 895 HD
Main boom 66 ft
Fixed jib length in (ft)
36
66
85
105
Radius (ft)
lbs
lbs
lbs
lbs
30
54.3
45
42.3
23.4
50
40.7
22.3
15.6
60
38.4
20.9
12.8
10.0
70
36.6
19.9
11.8
8.6
80
35.3
18.9
11.1
8.2
90
34.4
18.2
10.3
7.9
95
34.0
17.8
10.0
7.8
110
16.8
9.2
7.3
120
16.0
8.7
7.1
140
8.1
6.7
160
6.7
Main boom 152 ft
Fixed jib length in (ft)
36
66
85
105
Radius (ft)
lbs
lbs
lbs
lbs
38
50.8
55
42.0
22.6
65
40.7
21.9
13.3
75
39.8
21.1
12.8
8.8
80
39.1
20.7
12.5
8.7
100
37.1
19.6
11.4
8.2
120
35.5
18.5
10.5
7.7
140
31.3
17.7
9.7
7.3
170
22.4
16.7
8.8
6.9
200
15.3
8.2
6.6
215
8.0
6.5
235
6.5
Main boom 229 ft
Fixed jib length in (ft)
36
66
85
105
Radius (ft)
lbs
lbs
lbs
lbs
48.6
43.6
65
39.0
21.1
75
38.1
20.7
13.1
85
37.3
20.4
12.6
8.8
100
36.4
19.6
12.1
8.4
120
35.1
18.9
11.3
8.0
160
21.1
17.5
10.0
7.4
200
12.4
14.3
9.1
6.9
235
7.2
9.1
8.4
6.6
265
5.6
6.6
6.4
285
4.6
5.5
305
3.8
Main boom 94 ft
Fixed jib length in (ft)
36
66
85
105
Radius (ft)
lbs
lbs
lbs
lbs
29.9
55.5
45
44.1
26.2
55
41.1
22.3
13.6
65
39.3
21.1
12.8
9.0
70
38.5
20.6
12.4
8.8
80
37.2
19.8
11.6
8.4
90
35.9
19.0
11.0
8.1
100
35.0
18.5
10.4
7.8
120
33.8
17.3
9.4
7.3
150
15.4
8.4
6.8
170
7.9
6.6
190
6.6
Main boom 181 ft
Fixed jib length in (ft)
36
66
85
105
Radius (ft)
lbs
lbs
lbs
lbs
41.9
48.6
60
41.3
22.0
70
40.1
21.4
13.2
80
39.3
20.8
12.8
8.8
100
37.5
19.7
11.8
8.3
120
36.1
18.7
11.0
7.9
140
29.9
18.0
10.1
7.5
160
23.7
17.3
9.5
7.2
195
15.9
16.2
8.6
6.8
225
12.8
8.1
6.5
245
7.9
6.5
260
6.5
Main boom 248 ft
Fixed jib length in (ft)
36
66
85
105
Radius (ft)
lbs
lbs
lbs
lbs
51.3
41.3
70
37.3
20.4
80
36.5
20.1
12.8
85
36.1
19.9
12.6
9.6
120
33.3
18.7
11.4
8.1
160
20.1
17.4
10.2
7.4
200
11.5
13.4
9.2
6.9
240
5.7
7.5
8.4
6.6
250
4.6
6.3
7.4
6.5
280
3.2
4.2
5.2
300
2.5
3.4
310
2.5
Main boom 123 ft
Fixed jib length in (ft)
36
66
85
105
Radius (ft)
lbs
lbs
lbs
lbs
33.9
53.1
50
43.2
23.2
60
41.3
22.1
13.4
70
39.8
21.2
12.8
8.9
80
38.4
20.4
12.1
8.6
90
37.5
19.7
11.5
8.3
100
36.4
19.0
11.0
8.0
120
34.8
18.0
10.0
7.5
140
32.8
17.2
9.2
7.2
170
15.6
8.4
6.8
190
8.0
6.6
210
6.6
Main boom 209 ft
Fixed jib length in (ft)
36
66
85
105
Radius (ft)
lbs
lbs
lbs
lbs
45.9
45.7
65
39.9
21.4
70
39.4
21.1
15.1
80
38.5
20.8
12.8
9.7
100
37.1
19.7
12.0
8.4
120
35.6
18.9
11.2
8.0
140
28.4
18.1
10.5
7.6
180
17.4
16.9
9.3
7.0
215
11.1
13.0
8.6
6.7
245
8.9
8.1
6.5
265
7.6
6.4
285
6.4
Main boom 258 ft
Fixed jib length in (ft)
36
46
56
Radius (ft)
lbs
lbs
lbs
52.6
40.4
60
37.3
30.7
65
36.9
30.4
24.7
80
36.0
29.7
24.1
100
34.7
28.6
23.3
120
32.5
27.8
22.6
160
19.6
20.4
21.1
200
10.9
11.6
12.3
240
5.2
5.8
6.4
260
2.9
3.5
4.2
270
2.5
3.1
275
2.7
