9 TA 230 Litronic
Multi-function display
• Self-explanatory, high resolution
control unit with touchscreen
function
• Rear view monitoring
with camera as standard
• Air-conditioning can be controlled
using multi-function display
• Fuel consumption and machine
parameters monitored
• Service hour counter
Liebherr feel-good cab
• Cab mounted on elastic buffers
for low fatigue working
• Safe overview of the entire work
area through large windows
• Standard rear window protection
grille and air-conditioning system
• Easy access: wide steps
and ergonomic handles
Comfort
The operator’s cab on the Liebherr TA 230 Litronic dump truck was developed
to ensure easy operation and maximum visibility. This results in the ergonomic
control concept being fully intuitive. The large windows also provide perfect vis-
ibility of the entire working area. This allows the operator to remain alert and
concentrated throughout the day and ensures that he can continue to work at a
high capacity all the time.
Cab design a class above
Deluxe cab The modern cab provides the operator with all the
comforts he needs to enable him to work produc-
tively in a pleasant atmosphere. The cab is spa-
cious, has very good seat comfort and excellent
suspension, making it ergonomic and a pleasure to
work in.
Overview The single-piece windscreen and large side win-
dows provide a large field of vision without any
parts to get in the way. A good overview of the en-
tire working area makes work much easier for the
operator.
Simple operation
Control elements All the functions are arranged logically and easy to
use. The automatic gearbox, retarder and levers are
precise and sensitive in use. This helps the operator
retain his alertness and concentration throughout
the day.
Large display The clear operator information system is shown on
a large touchscreen display at the perfect point in
front of the operator. The drive can this identify all
the machine states at a glance.
Integral service benefits
Making work easier Service work can be carried out quickly since the
bearings are easily accessible all over the machine.
Simple servicing Electrically tilting operator’s cab and bonnet provide
easy and safe access to all service points and make
service work easier.
