8

R 926 – R 976 Litronic Attachment Ditch Cleaning Multi-User

Dimensions

Mono Boom 8.50 m

Stick 6.30 m

mm

V

5,700

W

3,100

X

12,800

Mono Boom 10.20 m

Stick 7.70 m

mm

V

5,900

W

3,300

X

14,500

Mono Boom 11.50 m

Stick 8.80 m

mm

V

14,650

W

2,700

X

15,650

mm

A

2,995

C

3,130

D

3,085

E

3,155

H

2,760

K

1,150

L

4,000

P

1,050

Q

495

S

2,590

U

4,920

N

500 600 750

B

3,158 3,190 3,340

G

3,180 3,180 3,480

Z

5,545

Multi-User

Ditch

Cleaning

R

9

3

6

R0030

H

D

E

U

L

K

P

S

B

G

Q

N

C

A

H

Z

V

X

W

R0057

H

D

E

U

L

K

P

S

B

G

Q

N

C

A

H

Z

V

X

W
