Powering up the switch – Belkin F1DZ104T User Manual
Page 6
1.
Connect the included 12V DC, 1A power supply unit into an available
power outlet.
2.
Attach the barrel plug into the power jack located on the rear of the
Switch to power the unit.
The LEDs should illuminate.
Powering Up the Switch
2
VGA
VGA
VGA
VGA
VGA
USB
USB
USB
USB
04
04
04
03
03
03
02
02
02
01
01
01
