ASSEMBLY INSTRUCTIONS
READ ALL SAFETY WARNINGS & ASSEMBLY INSTRUCTIONS CAREFULLY
BEFORE ASSEMBLING OR OPERATING YOUR GRILL.
WE RECOMMEND TWO PEOPLE WORK TOGETHER WHEN ASSEMBLING THIS UNIT.
The following provided tools are required to assemble this ProSeries ™ 7341 Gas Grill:
• Flathead Screwdriver
• Hex Nut Wrench
21
1 Grease Tray
1 Heat Shield
1 Left Side Cart Panel
1 Back Panel
1 Door Bracket
1 Right Side Cart Panel
2 Doors
2 Door Handles
1 Loop Strap Bracket
1 Cart Base
2 Locking Casters
1 Tank Lock Wire
2 Hubcaps
2 Rubber Wheels
PARTS LIST:
1 Grill Body Assembly
1 Left Side Table
1 Side Burner Assembly
1 Side Table Towel Rack
1 Side Burner Towel Rack
1 Left Side Table Front Panel
1 Side Burner Front Panel
1 Electronic Igniter Cap
1 Electronic Igniter Spring
1 Side Burner Knob
1 Side Burner Bezel
1 Side Burner Grate
1 Warming Rack
3 Cooking Grills
4 Heat Distribution Plates
