Quick Start Guide
Connecting Your ADSL Router
1. Connect this router to a LAN (Local Area Network) and the ADSL/telephone (ADSL) network.
2. Power on the device.
3. Make sure the PWR and SYS LEDs are lit steadily and that the LAN LED is lit.
4. Connect an RJ11 cable to VoIP port when connecting to an analog phone set.
5. Connect RJ-11 cable to LINE Port when connecting to the telephone wall jack.
Connect more
computers
Analog Phone
ADSL
Splitter
ADSL Phone
Line
Switching/
HUB
(802.11g is not supported in BiPAC 7401VP)
4
