4
MicroSystem9000 II Specifications
System Frequency Response (±3dB)
29–20,000Hz
Recommended Amplifier Power
15–125 watts
Nominal Impedance
8 ohms
Sensitivity (1 watt [2.83v] at 1m)
89dB
Subwoofer Amplifier Power
120 watts continuous, 4
Ω
; <0.5% THD, 100 watts, 20–150Hz
Bass Unit (Micro90pv II subwoofer)
10" (250mm) down-firing DCD copolymer with butyl rubber surround
Midrange (all)
3
1
⁄
2
" (89mm) copolymer with butyl rubber surround
Tweeter (Micro90x II, Micro90c II)
1" (25mm) anodized aluminum dome with AMD
Tweeter (Micro80x II)
3
⁄
4
" (19mm) dome
Crossover Frequency
3800Hz (Micro90x II); 2500Hz (Micro90c II); 4500Hz (Micro80x II); 150Hz (Micro90pv II)
Dimensions (HxWxD)
Sub: 16
1/2
x 11
7/8
x 16
1/8
" (420 x 302 x 410mm)
Front and Rear Sats: 6
7
⁄
8
x 4
1
⁄
4
x 5
3
⁄
4
" (175 x 108 x 146mm)
Center: 4
3
⁄
8
x 8 x 5
1
⁄
8
" (111 x 200 x 129mm)
Weight
Micro90pv II: 30 lbs (14kg); Micro90x II: 5 lbs ea (1.8kg); Micro80x II: 4 lbs ea. (1.8kg);
Micro90c II: 8 lbs (3.6kg)
Finish
Subwoofer: Black; Satellites and Center: Black or Silver
MicroSystem9500 Specifications
System Frequency Response (±3dB)
26–20,000Hz
Recommended Amplifier Power
25–150 watts
Nominal Impedance
8 ohms
Sensitivity (1 watt [2.83v] at 1m)
89dB
Subwoofer Amplifier Power
300 watts continuous; <0.5% THD, 250 watts 4
Ω
, 20–150Hz
Bass Unit (Micro95pv subwoofer)
12" (300mm) downfiring DCD copolymer with butyl rubber surround
Midrange (Micro90x II and Micro90c II)
3
1
⁄
2
" (89mm) copolymer with butyl rubber surround
Tweeter (Micro90x II, Micro90c II)
1" (25mm) anodized aluminum dome with AMD
Crossover Frequency
3800Hz (Micro90x II); 2500Hz (Micro90c II); 150Hz (Micro95pv)
Dimensions (HxWxD)
Sub: 18 x 14
1/4
x 19" (458 x 363 x 483mm)
Sats: 6
7
⁄
8
x 4
1
⁄
4
x 5
3
⁄
4
" (175 x 108 x 146mm)
Center: 4
3
⁄
4
x 12 x 5
1
⁄
4
" (121 x 305 x 133mm)
Weight
Micro95pv: 40 lbs (18kg); Micro90x II: 5 lbs ea (1.8kg); Micro90c II: 8 lbs (3.6kg)
Finish
Subwoofer: Black; Satellites and Center: Black or Silver
