RFX9400 Starter’s Guide
Unpacking the Extender
Pronto Wireless Extender
Front Panel
Antenna
Configuration switch
• In Stand-alone Mode:
changes the RF
channel.
• In Network Mode:
indicates the
connection type.
Power input
4 IR outputs
4 dipswitches for
the IR outputs
Back Panel
Extender ID switch Ethernet input
(RJ45)
Stand-alone/
Network switch
2 Dual IR Emitters 2 Mini-jack IR Cables Power Adapter Configuration Cable
Crossed Ethernet cable
WiFi LED
Ethernet LED
Busy LED
Power LED
