RS-232 Baud Rate Change cont’d.
Bit 2 stop bit works in conjunction with bits 1 and bit 0.
Table 16. Stop Bit Setup
Bit 2 Word length (bits) Stop bit length
0 5, 6, 7, 8 1*
1 5 1½
1 6, 7, 8 2
* Setup default value.
Bits 1 and 0 set the word length.
Table 17. Word Length
Bit 1 Bit 2 Word length
0 0 5
0 1 6
1 0 7
1 1 8*
* Setup default value.
