44
F I D 4 6 M a i n f r a m e P a r t s L i s t
F I D 4 6 L a b e l s / D e c a l s L i s t
F I D 4 6 P a d s L i s t
Part numbers are required when ordering parts.
KEY# QTY PART# DESCRIPTION
A 1 FID46FL-A FRONT LEG
B 1 FID46MF-B MAINFRAME
C 1 FID46BL-C BACK LEG
D 2 FID46BP-D BRACE PLATE
E 1 FID46AC-E ADJUSTMENT CARRIAGE
F 1 FID46CAT-F CHROME ADJUSTMENT TUBE
G 1 FID46SP-G SEAT PIVOT
H 2 FID46SB-H SEAT BRACE
J 2 FID46BB-J BACK BRACE
K 1 FID46LSPH-K LEFT SEAT PAD HANDLE
L 1 FID46RSPH-K RIGHT SEAT PAD HANDLE
M 1 FID46LBKH-M LEFT BACK PAD HANDLE
N 1 FID46RBKH-N RIGHT BACK PAD HANDLE
R 1 FID46PA-R PIVOT ARM
S 1 FID46PS-S PIVOT SHAFT
T 1 FID46MP-T MAIN POST
KEY# QTY PART# DESCRIPTION
1 DWRULE-4 WARNING LABEL FOR RULES
1 DWSM-5 WARNING LABEL FOR MAINTENANCE
F I D 4 6 H a r d w a r e L i s t
KEY# QTY PART# DESCRIPTION
1 10 PEC12 PLASTIC END CAP 1"X2"
2 1 BC2 PLASTIC BALL-END CAP 2"
3 2 BEC250 PLASTIC BALL-END CAP 2.5"
4 1 BC3 PLASTIC BALL-END CAP 3"
5 4 RFC3 3" ROUND FOOT CAP
6 6 PFREC2.5 PLASTIC ROLLER END CAP
7 4 REC1.25 ID. 1 1/4" ROUND HANDLE END CAP
8 1 OASC2 OLY ADAPTER SLEEVE
9 6 FOAM48 FOAM ROLLER 4"X8" / UPHOLESTERED
10 3 FRB18.5 FOAM ROLLER BAR 18 1/2"
11 4 FG1.6 FOAM GRIP 1.6" OD (VARIOUS LENGTHS)
12 1 RDOP2 RUBBER DONUT (FOR OLY. WEIGHT POST)
13 2 PIN4 ADJUSTMENT PIN
14 2 ROLWH3 ROLLER WHEEL 3"
15 1 LLPPH LARGE LOCKING POP PIN HANDLE
16 1 RS1 RUBBER STOPPER
17 2 BB3220 OILITE BUSHING 32mm OD X 20mm ID
18 2 PB6565 PLASTIC BUSHING 65mm X 65mm
19 1 PB4545 HIGH-LOW PLASTIC BUSHING 45mm X 45mm
20 22 BB2010 OILITE BUSHING 20mm OD X 10mm ID
21 1 HEX10210PTB HEX BOLT 10mmX210mm PARTIAL THREAD
22 2 HEX10165PTB HEX BOLT 10mmX165mm PARTIAL THREAD
23 1 HEX10110PTB HEX BOLT 10mmX110mm PARTIAL THREAD
24 2 HEX1080PTB HEX BOLT 10mmX80mm PARTIAL THREAD
25 2 HEX1060PTB HEX BOLT 10mmX60mm PARTIAL THREAD
26 8 HEX1040FTB HEX BOLT 10mmX40mm FULL THREAD
28 3 RAH1020FTB ROUND ALLEN HEAD 10mmX20mm FULL THREAD BOLT
29 4 SNCS1095 SQUARE NECK CARRIAGE BOLT 10mm X 95mm
30 8 HEX860FTB HEX BOLT 8mmX60mm PARTIAL THREAD
31 2 HEX845FTB HEX BOLT 8mmX45mm PARTIAL THREAD
32 19 NLN10 NYLON LOCK NUT 10mm
33 2 NLN8 NYLON LOCK NUT 8mm
34 3 WFLT1030 FLAT WASHER 10mm X 30mm
35 3 WSW10 SPRING LOCK WASHER 10mm
36 34 WFLT10 FLAT WASHER 10mm
37 8 WSW8 SPRING LOCK WASHER 8mm
38 12 WFLT8 FLAT WASHER 8mm
39 2 PSEC175175 PLASTIC SQUARE END CAP 1.75"X1.75"
40 1 OLYCLR1.84 OLYMPIC SPRING COLLAR 1 7/8"
KEY# QTY PART# DESCRIPTION
P 1 FID46SP-P SEAT PAD
Q 1 FID46BP-Q BACK PAD
