43 Barracuda NG Network Access Client - Administrator’s Guide
3.2.1 Rules Incoming / Outgoing
Rules controlling incoming traffic are arranged in the Rules Incoming view, rules controlling outgoing
traffic are arranged in the Rules Outgoing view (figure 3–1).
3.2.2 Context Menu
Select and right-click a list entry to display the following context menu:
Fig. 3–2 Rules Outgoing
Table 3–1 Rule window - Context menu
Item Description
Show Source
Addresses … Opens a window displaying all source addresses affected by the selected rule.
Show Destination
Addresses … Opens a window displaying all destination addresses affected by the selected rule.
Show Services … Opens a window displaying all services affected by the selected rule.
Show Applications … Opens a window displaying all applications affected by the selected rule.
Show Adapters… Opens a window displaying all adapters affected by the selected rule.
Show Users… Opens a window displaying all users affected by the selected rule.
Select Overlapping… As a connection request can match several conditions, the rules' succession within a rule set is very important. If incorrectly
ordered, rules might interfere with one another. The function
Select Overlapping is meant to help avoiding configuration
mistakes. When applied to a selected rule, all rules possibly interfering with it are highlighted. In the majority of cases, the
overlap is a harmless outcome of the use of very openly defined objects such as
InterNet .
Edit … Opens the rule configuration dialog for the selected rule (3.2.4 Rule Configuration, page 45).
