Barracuda Networks VERSION SP4 - Manual (Page 106)

104 Barracuda NG Personal Firewall
9.8.2 Rules
The Rules view allows manual rule configuration. Rules controlling incoming traffic are arranged in the
Incoming tab, rules controlling Outgoing traffic are arranged in the Outgoing tab (figure 9–16).
9.8.3 Context Menu
Select and right-click a list entry to display the following context menu:
Personal Firewall rule sets are not capable of RCS.
Fig. 9–16 Rules window
Table 9–6 Rule window - Context menu
Item Description
Show Source Addresses … Opens a window displaying all source addresses affected by the selected rule.
Show Destination Addresses … Opens a window displaying all destination addresses affected by the selected rule.
Show Services … Opens a window displaying all services affected by the selected rule.
Show Applications … Opens a window displaying all applications affected by the selected rule.
Show Adapters Opens a window displaying all adapters affected by the selected rule.
Show Users Opens a window displaying all users affected by the selected rule.
Select Overlapping As a connection request can match several conditions, the rules' succession within a rule set is very
important. If incorrectly ordered, rules might interfere with one another. The function
Select Overlapping is
meant to help avoiding configuration mistakes. When applied to a selected rule, all rules possibly interfering
with it are highlighted. In the majority of cases, the overlap is a harmless outcome of the use of very openly
defined objects such as
InterNet .
Edit … Opens the rule configuration dialog for the selected rule (9.8.5 Rule Configuration, page 105).
New … Opens the rule configuration dialog for a new rule (9.8.5 Rule Configuration, page 105).
Delete Deletes the selected rule(s).
Copy Copies the selected rule(s) to the clipboard.
Button bar
