Brinkmann ProSeries 4415 User Manual
Page 27
26
Step 9
Attach side table front panel to side
table with two M6 nuts and one
M6 x 15mm bolt.
Step 10
Attach side burner front panel to
side burner with two M6 nuts and
one M6 x 15mm bolt.
Step 11
Attach side table to left side of cart
frame assembly. Insert four
M6 X 15mm bolts halfway into cart
frame assembly.
Step 12
Place table keyholes over bolts and
slide toward bottom of grill, then
tighten securely. Fasten side table
front panel to grill body with two
M4 X 10mm bolts and two
M4 washers.
