5
w w w . b i s s e l l . c o m 8 0 0 . 2 3 7 . 7 6 9 1
the only tool you’ll need to assemble your vacu-
um cleaner is a philips head screwdriver.
Attach handle to vacuum
1. Locate the vacuum handle and remove
the screw packet taped to the base of the
handle.
2. Stand the vacuum upright and slide the base
of the handle firmly into the grooves at the
top of the vacuum body.
3. Check to be sure the handle is fitted to the
vacuum body. If there is a gap in front, con-
tinue to push firmly until the handle is flush.
4. Insert the screw provided from the screw
packet into the existing hole. Tighten secure-
ly with a screwdriver.
Attach vacuum hose and tools
1. Attach the Twist ‘n Snap™ hose by lining up
the tabs on the base with the corresponding
notches on the back of the vacuum.
2. Turn the Twist ‘n Snap hose to the right to
lock the hose into place.
3. Grasping the Quick Reach handle, slide the
end of the hose wand onto the hose wand
base. Snap the hose into the hose clip.
notE: the powerfoot will not suction
properly unless the hose wand is
firmly attached.
4. Snap the extension wand and the crevice
tool together into the storage clip.
5. Snap the combination tool into the storage
clip.
6. Attach the TurboBrush by aligning the small
holes near the brush roll with the tabs at
the bottom of TurboBrush housing. Snap
TurboBrush into place.
A
ssembly
Hose
Wand
2.
4.
2.
6.
4.
4.
5.
3.
