Briggs & Stratton 120400 - Manual (Page 13)

120400
Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.
6217–13 Assemblies include all parts shown in frames. 7C–1/2003
13
130 691181 Valve–Throttle
130A 691203 Valve–Throttle
Used on Type No(s).
0120, 0133, 0135,
0137, 0138.
133 398187 Float–Carburetor
134 D 398188 Kit–Needle/Seat
137 D
z 693981 Gasket–Float Bowl
146 690979 Key–Timing
155 698214 Plate–Cylinder Head
161 692579 Base–Air Cleaner
(Flat Panel Air
Cleaner)
(Used Before Code
Date 02100800).
––––––– Note –––––
696063 Base–Air
Cleaner
(Flat Panel Air
Cleaner)
(Used After Code Date
02100700).
163 KzD 272948 Gasket–Air Cleaner
(Flat Panel)
(Used Before Code
Date 02100800).
163A KzD 693458 Gasket–Air Cleaner
(High Mount)
(Used Before Code
Date 02110100).
Used on Type No(s).
0109, 0119, 0124,
0213.
163B 696024 Gasket–Air Cleaner
(Flat Panel Air
Cleaner)
(Used After Code Date
02100700).
163C 696979 Gasket–Air Cleaner
(High Mount)
(Used After Code Date
02103100).
Used on Type No(s).
0109, 0119, 0124,
0213.
184 691685 Screw
(Muffler Strap)
186 692317 Connector–Hose
187 691050 Line–Fuel
(Straight)
(Cut to Required
Length)
187A 692601 Line–Fuel
(Molded)
187B 693401 Line–Fuel
(Molded)
188 690877 Screw
(Control Bracket)
190 692127 Screw
(Fuel Tank)
190A 690877 Screw
(Fuel Tank)
(Used Before Code
Date 99070500).
192 694543 Adjustor–Rocker Arm
209 692571 Spring–Governor
(Silver)
––––––– Note –––––
693206 Spring–
Governor
(Yellow)
Used on Type No(s).
0023, 0119, 0120,
0121, 0124, 0135,
0147.
691798 Spring–
Governor
(Brown)
Used on Type No(s).
0036, 0101, 0105,
0111, 0113, 0115,
0116, 0117, 0118,
0119, 0121, 0124.
209A 691278 Spring–Governor
219 693578 Gear–Governor
220 691724 Washer
(Governor Gear)
222 695742 Bracket–Control
222A 694253 Bracket–Control
222B 694263 Bracket–Control
(Used Before Code
Date 99070500).
Used on Type No(s).
0036, 0101, 0111,
0113.
222C 696288 Bracket–Control
Used on Type No(s).
0124.
227 692573 Lever–Governor
Control
238 691300 Cap–Valve
240A 298090 Filter–Fuel
265 691024 Clamp–Casing
267 692577 Screw
(Casing Clamp)
268 691025 Casing–Control Wire
(72” Long)
(Cut to Required
Length)
269 691026 Wire–Control
(78” Long)
(Cut to Required
Length)
270 691027 Nut
(Control Wire Casing)
271 691028 Lever–Control
271A 695743 Lever–Control
271B 694256 Lever–Control
276 D
z 271716 Washer–Sealing
281 694252 Panel–Control
(Used After Code Date
99070400).
281A 693407 Panel–Control
(Used Before Code
Date 99070500).
285 692595 Strap–Muffler
286 698611 Module–Oil Sensor
(Used After Code Date
03010500).
––––––– Note –––––
698317 Module–Oil
Sensor
(Used Before Code
Date 03010600).
K Included in Engine Gasket Set–Ref. No.358.
D
Included in Carburetor Overhaul Kit–Ref. No. 121.
z Included in Carburetor Gasket Set–Ref. No. 977.
∅ Included in Valve Gasket Set–Ref. No 1095.
REF. PART REF. PART REF. PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
