Briggs & Stratton 120400 - Manual (Page 12)

120400
Illustrations cover a range of engines. Parts shown without corresponding text may not be used on your specific engine.
6217–12 Assemblies include all parts shown in frames. 7C–1/2003
12
40 692194 Retainer–Valve
45 690977 Tappet–Valve
46 693404 Camshaft
46A 694831 Camshaft
––––––– Note –––––
695285 Camshaft
Used on Type No(s).
0127.
51 KzD∅ 692555 Gasket–Intake
(2 Required)
55 691422 Housing–Rewind
Starter
58 693389 Rope–Starter
(Cut to Required
Length)
59 805957 Insert–Grip
60 715257 Grip–Starter Rope
(2 Piece)
60C 695740 Grip–Starter–Rope
Used on Type No(s).
0139.
65 690837 Screw
(Rewind Starter)
65A 692608 Screw
(Rewind Starter)
79 694511 Case–Gear Reduction
82 690369 Screw
(Gear Reduction Case)
82A 691122 Screw
(Gear Reduction Case)
83 690374 Shaft–Auxiliary Drive
84 691121 Plug–Breather
85 692551 Screw
(Gear Cover to Gear
Reduction Case)
86 690608 Cover–Gear
87 691582 Seal–Gear Reduction
88 691600 Gasket–Gear
Reduction Cover
95 691636 Screw
(Throttle Valve)
97 690024 Shaft–Throttle
98 398185 Kit–Idle Speed
(Carburetor)
98A 493280 Kit–Idle Speed
(Control Bracket)
104 D 691242 Pin–Float Hinge
108A 691182 Valve–Choke
(.223” Diameter Holes,
Stamped 223471)
. 108B 692567 Valve–Choke
(.156” Diameter Holes,
Stamped 224449)
109 690023 Shaft–Choke
(Straight Handle)
109A 693628 Shaft–Choke
Used on Type No(s).
0109, 0119, 0124,
0213.
117 694176 Jet–Main
(Standard)
(Used Before Code
Date 02100800).
––––––– Note –––––
690048 Jet–Main
(Standard)
(Used After Code Date
02100700).
690048 Jet–Main
(Standard)
(Used Before Code
Date 02110100).
Used on Type No(s).
0109, 0119, 0124,
0213.
698344 Jet–Main
(Standard)
(Used After Code Date
02103100).
Used on Type No(s).
0109, 0119, 0124,
0213.
498976Jet–Main
(Standard)
Used on Type No(s).
0120, 0133, 0135,
0137, 0138.
691428 Jet–Main
(Standard)
Used on Type No(s).
0145.
118 690048 Jet–Main
(High Altitude)
(Used Before Code
Date 02100800).
––––––– Note –––––
498976 Jet–Main
(High Altitude)
(Used After Code Date
02100700).
498977 Jet–Main
(High Altitude)
(Used Before Code
Date 02110100)
Used on Type No(s).
0109, 0119, 0124,
0213.
694176 Jet–Main
(High Altitude)
(Used After Code Date
02103100).
Used on Type No(s).
0109, 0119, 0124,
0213.
694975 Jet–Main
(High Altitude)
Used on Type No(s).
0120, 0133, 0135,
0137, 0138.
695042 Jet–Main
(High Altitude)
Used on Type No(s).
0145.
121 695157 Kit–Carburetor
Overhaul
121A 696998 Kit–Carburetor
Overhaul
(High Vent)
122 D 693749 Spacer–Carburetor
125 694174 Carburetor
(Used Before Code
Date 02100800).
––––––– Note –––––
698474 Carburetor
(High Vent)
(Used After Code Date
02100700).
693518 Carburetor
(Used Before Code
Date 02110100).
Used on Type No(s).
0109, 0119, 0124,
0213.
698475 Carburetor
(High Vent)
(Used After Code Date
02103100).
Used on Type No(s).
0109, 0119, 0124,
0213.
694508 Carburetor
Used on Type No(s).
0120, 0133, 0135,
0137, 0138.
127 D 691739 Plug–Welch
(5/16” Diameter)
127A D 694468 Plug–Welch
(3/8” Diameter)
127B 691585 Plug–Welch
K Included in Engine Gasket Set–Ref. No.358.
D
Included in Carburetor Overhaul Kit–Ref. No. 121.
z Included in Carburetor Gasket Set–Ref. No. 977.
∅ Included in Valve Gasket Set–Ref. No 1095.
REF. PART REF. PART REF. PART
NO. NO. DESCRIPTION NO. NO. DESCRIPTION NO. NO. DESCRIPTION
