MatrixPRO-II 3G/HD/SD-SDI Routers

Rev. 1.1

MatrixPRO-II HD/3G SDI Series –User’s Guide - Rev. 1.1

31

A single X-point Take command can switch multiple X-points. You will however receive one
response for each X-point that is switched.

Example:

Command

Echo

Desired action

X l1 1 12

X l1 1 12

Switch input 1 to output 12 in level 1


B.2 Request X-Point Status

This command is used to requests the X-point status of all destinations on a specified level.

Command:

s l [*CC]

Response:

%

x l

[x l …]

[*CC]



Example:

Command

Echo

Desired action

s l1

X l1 15 0
X l1 15 1
X l1 15 2
X l1 15 3
X l1 15 4
X l1 15 5
X l1 15 6
X l1 15 7
X l1 15 8
X l1 15 9
X l1 15 10
X l1 15 11
X l1 15 12
X l1 15 13
X l1 15 14
X l1 15 15

Report x-point status in level 1
