2.4 Video specifications
Supported formats:
Broadcast:
- 270Mbps – 2.97Gbps;
- DVB-ASI, SMPTE 259M, SMPTE 292M,
SMPTE 424M;
- 2K, 2048x1556/23.98 and 24.
Electrical signal inputs:
Standard:
SMPTE 259M / SMPTE 292M / SMPTE 424M.
Data rate: 270Mbps – 1.485Gbps / 2.97Gbps.
Connector: 75 ohm BNC female.
Impedance: 75 ohm nominal.
Return loss: - > 15dB (5MHz-1.485Ghz);
- > 10dB (1.5GHz – 3GHz).
Cable equalization,
- Automatic up to 70m @ 2.97Gbps,
typical Belden 1694A;
- Automatic up to 100m @ 1.485Gbps,
typical Belden 1694A.
- Automatic up to 300m @ 270Mbps, typical Belden
8281.
Electrical signal outputs:
Connector:
75 ohm BNC female.
Impedance: 75 ohm nominal.
Return loss: - > 15dB (5MHz-1.485Ghz);
- > 10dB (1.5GHz – 3GHz).
Signal level: 800mVp-p ±10%.
Rise/fall time: 20% - 80%
- SD limit: 0.4ns – 1.5ns, < 0.5ns rise/fall variation;
- HD limit: < 270ps, < 100ps rise/fall variation;
- 3G-HD limit: < 135ps, < 50ps rise/fall variation;
Amplitude overshoot: < 10%.
Signal polarity: Non-inverting electrical with respect to inputs.
Signal transition:
Timing jitter:
- SD: < 0.2 UI
- 3G-HD / HD: < 1 UI.
Alignment jitter: - SD: < 0.2 UI
- 3G-HD / HD: < 0.2 UI.
Reference inputs:
Number of inputs: 1
Connector:
75 ohm BNC female, loop-thru.
Return loss: >40dB (100 kHz – 5 MHz);
>35dB (5-10 MHz).
Signal format: NTSC or PAL Black&Burst or HD Tri-Level according to SMPTE 274M,
SMPTE 276M.
Signal level: Nominal 1.0Vp-p.
